– 2 – General Power requirements 120 V AC, 60 Hz Power consumption 13 W Dimensions (approx.) 430 × 69 × 252 mm (17 × 2 3⁄4 × 10 in.) (w/h/d) incl. projecting parts Mass (approx.) 2.8 kg (6 lb 3 oz) Operating temperature 41 ˚F to 95 ˚F (5 ˚C to 35 ˚C) Operating humidity 25 % to 80 % Supplied accessories - Audio/video connecting cord (1) - Remote commander (remote) (1) - Size AA (R6) batteries * The signals from AUDIO OUT connectors are measured. When you play PCM sound tracks with a 96 kHz sampling frequency, the output signals from the DIGITAL OUT (OPTICAL, COAXIAL) are converted to 48 kHz (sampling frequency). Design and specifications are subject to change without notice.
Page 2
– 3 – - DIFFERENT PARTS LIST 8-1. EXPLODED VIEWS 8-1-1. CASE ASSEMBLY (See Service Manual Page 8-1.) - : Points changed parts. NOTE: - -XX and -X mean standardized parts, so they may have some difference from the original one. - Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. KNOB, BALANCE (WHITE) . . . (RED) ↑↑ Parts Color Cabinet's Color- The mechanical parts with no reference number in the exploded views are not supplied. 1010 11 4 not supplied 53 10 9 7 8 6 2 1 1 X-3950-804-1 PANEL ASSY, FRONT 3 4-217-485-01 EMBLEM (5-A), SONY 4 3-975-726-61 EMBLEM, DVD 5 3-059-323-41 COVER, TRAY 6 3-059-322-41 STICK, CURSOR 10 3-710-901-61 SCREW, TAPPING 11 3-062-941-21 CASE 1 X-3950-392-1 PANEL ASSY, FRONT 3 4-963-404-21 EMBLEM (5-A), SONY 4 3-975-726-71 EMBLEM, DVD 5 3-061-152-01 COVER, TRAY 6 3-059-322-31 STICK, CURSOR 10 3-710-901-11 SCREW, TAPPING not supplied DVP-S360: US DVP-S363: US Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark ]- -\ -== = =
