Sony dps v 55 service manual
This is the 32 pages manual for sony dps v 55 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony dps v 55 service manual (Ocr-read)
Page 1
Ð 2 Ð ATTENTION AU COMPOSANT AYANT RAPPORT Ë LA SƒCURITƒ! LES COMPOSANTS IDENTIFIƒS PAR UNE MARQUE ! SUR LES DIAGRAMMES SCHƒMATIQUES ET LA LISTE DES PIéCES SONT CRITIQUES POUR LA SƒCURITƒ DE FONCTIONNEMENT. NE REMPLACER CES COM- POSANTS QUE PAR DES PIéCES SONY DONT LES NUMƒROS SONT DONNƒS DANS CE MANUEL OU DANS LES SUPPLƒMENTS PUBLIƒS PAR SONY. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB- LISHED BY SONY. TABLE OF CONTENTS 1. SERVICING NOTES ............................................... 2 2. GENERAL ................................................................... 5 3. DISASSEMBLY ......................................................... 9 4. TEST MODE .............................................................. 11 5. DIAGRAMS ................................................................. 13 5-1. Printed Wiring Board Ð MAIN Section Ð ...................... 15 5-2. Schematic Diagram Ð MAIN Section (1/3) Ð ................. 17 5-3. Schematic Diagram Ð MAIN Section (2/3) Ð ................. 19 5-4. Schematic Diagram Ð MAIN Section (3/3) Ð ................. 21 5-5. Printed Wiring Boards Ð PANEL Section Ð .................. 23 5-6. Schematic Diagram Ð PANEL Section Ð ....................... 25 5-7. IC Pin Function Description ........................................... 28 6. EXPLODED VIEWS ................................................ 32 7. ELECTRICAL PARTS LIST ............................... 34
Page 2
Ð 3 Ð SECTION 1 SERVICING NOTES ROM VERSION CHECK ¥ This system have ROM version check function consequently key set up of when power on. (No need in open the main body) 1) Press three buttons [ENTER] , [EXIT] , and [POWER] simul- taneously, in the power off. 2) Fluorescent indicator tube indicate ROM version about 1 sec- ond, and restart system. UPDATING THE ROM (IC704) VERSION The ROM version may be updated in order to fix the bugs or add the functions. ÒAll Initialize!!Ó is displayed and internal data are automatically initialized, if the power is turned on after replacing the ROM. In this case, the user preset data and system data cannot be restored. Please notify the users of this matter. If the same version ROM was replaced for repair, not for version updating, the data are not initialized unless internal data are dam- aged. Nevertheless, to avoid a trouble, it is recommended to save inter- nal data using the Data Filer, etc. The initial version of the ROM will be Ver.1.00 part No. 8-759- 499-74. Note:Internal data mentioned above are all saved in the IC702 (CY6225LL) when the power is turned off. REPLACING THE BATTERY The built-in battery must be replaced, if ÒBattery Low!Ó is dis- played at the power ON. When the battery was used up com- pletely, internally saved data (system data, user preset data, etc.) are all cleared, and ÒExt. RAM Error!Ó ÒAll Initialize!!Ó are dis- played at the power ON, then the data are initialized to the factory setting automatically. In this case, the user preset data and system data cannot be restored. Please notify the users of this matter. Unless ÒExt. RAM ErrorÓ ÒAll Initialize!!Ó are displayed at the power ON, internal data are still saved, and in this case, internal data are kept unchanged if the battery is replaced while the power is turned on. To avoid a trouble, it is recommended to save internal data using the Data Filer, etc. This information is given to the users on page 19 of the Operation Manual. Ver 1.00 Flexible Circuit Board Repairing ¥ Keep the temperature of the soldering iron around 270 ûC during repairing. ¥ Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). ¥ Be careful not to apply force on the conductor when soldering or unsoldering. Notes on chip component replacement ¥ Never reuse a disconnected chip component. ¥ Notice that the minus side of a tantalum capacitor may be dam- aged by heat. ADVARSEL Eksplosjonsfare ved feilaktig skifte av batteri. Benytt samme batteritype eller en tilsvarende type anbefalt av apparatfabrikanten. Brukte batterier kasseres i henhold til fabrikantens instruksjoner. VARNING Explosionsfara vid felaktigt batteribyte. AnvŠnd samma batterityp eller en likvŠrdig typ som rekommenderas av apparattillverkaren. Kassera anvŠnt batteri enligt gŠllande fšreskrifter. VAROITUS Paristo voi rŠjŠhtŠŠ, jos se on virheellisesti asennettu. Vaihda paristo ainoastaan laitevalmistajan suosittelemaan tyyppiin. HŠvitŠ kŠytetty paristo valmistajan ohjeiden mukaisesti.ADVARSEL! Lithiumbatteri-Eksplosionsfare ved fejlagtig hŒndtering. Udskiftning mŒ kun ske med batteri af samme fabrikat og type. LevŽr det brugte batteri tilbage til leverand¿ren. CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturerÕs instructions.
