DP-R F6000

Notes on chip component replacement
0 Never reuse a disconnected chip component,
0 Notice that the minus side of a tantalum capacitor may be
damaged by heat.

Unleaded solder

Boards requiring use of unleaded solder are primed with the lead
free mark (LF) indicating the solder contains no leadr

(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size)

LEAD FREE MARK

Unleaded solder has the following characteristics.

0 Unleaded solder melts at a temperature about 40°C higher than
ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350°C.
Caution: The printed pattern (copper foil) may peel away if
the heated tip is applied for too long, so be careful!

0 Strong viscosity
Unleaded solder is more viscous (sticky, less prone to flow)
than ordinary solder so use caution not to let solder bridges
occur such as on IC pins, etc.

o Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.

- Repaier DP-RF6000 with MDR-RFGOOOr

TABLE OF CONTENTS

Specifications 1
1 . GENERAL rrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrr 3
2-1, Block Diagrams iiiiiiiiiiiiiiiiiiii
2-2. Printed Wiring Board - TX Board Section (Side A)
23, Printed Wiring Board e TX Board Section (Side B)
24. Printed Wiring Board

- FUNCTION, CHARGE Boards Section ~ rrrrrrrrrrrrrrrrrrr 8
2-5. Schematic Diagram - TX Board Section (1/4) -
2»6, Schematic Diagram ~ TX Board Section (2/4) -
2»7. Schematic Diagram - TX Board Section (3/4) -
2-8. Schematic Diagram - TX Board Section (3/4) -
2-9. Schematic Diagram

A TX (4/4), FUNCTION, CHARGE Boards Section ~ 13
2»10r lC Pin Function Descriptions rrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrr
3. EXPLODED VIEWS
3-1 Processor Section rrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrr 20
4. ELECTRICAL PARTS LIST .................................. 21
