Sony d f 415 service manual
This is the 43 pages manual for sony d f 415 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony d f 415 service manual (Ocr-read)
Page 1
Ñ 2 Ñ SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Flexible Circuit Board Repairing ¥ Keep the temperature of the soldering iron around 270°C during repairing. ¥ Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). ¥ Be careful not to apply force on the conductor when soldering or unsoldering. Notes on chip component replacement ¥ Never reuse a disconnected chip component. ¥ Notice that the minus side of a tantalum capacitor may be damaged by heat. DANGER Invisible laser radiation when open and interlock failed or defeated. Avoid direct exposure to beam. This Compact Disc player is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT label is located on the bottom exterior. D-F400 AC power adaptor (1) Earphones with remote control (1) Rechargeable battery (1) AC plug adaptor (1) D-F411 AC power adaptor (1) Headphones (1)* 1 Earphones (1)* 2 Connecting cord (Phono plug ´ 2 « stereo miniplug) (1)* 3 AC plug adaptor (1)* 4 *1Supplied with US model *2Not supplied with US model *3Not supplied with AEP, French and UK models *4Supplied with E33, E13 and Saudi Arabia models D-F415 AC power adaptor (1) Headphones with remote control (1)* 1 Earphones with remote control (1)* 2 Connecting cord (Phono plug ´ 2 « stereo miniplug) (1)* 1 Rechargeable battery (1) AC plug adaptor (1)* 3 *1Supplied with US model *2Not supplied with US model *3Not supplied with E13 model Design and specifications are subject to change without notice. ATTENTION AU COMPOSANT AYANT RAPPORT Ë LA SƒCURITƒ! LES COMPOSANTS IDENTIFƒS PAR UNE MARQUE ! SUR LES DIAGRAMMES SCHƒMATIQUES ET LA LISTE DES PIéCES SONT CRITIQUES POUR LA SƒCURITƒ DE FONCTIONNEMENT. NE REMPLACER CES COMPOSANTS QUE PAR DES PIéSES SONY DONT LES NUMƒROS SONT DONNƒS DANS CE MANUEL OU DANS LES SUPPƒMENTS PUBLIƒS PAR SONY.
