Playing a CD in a car You can use your player in a car as illustrated below. To connect your CD player to a car cassette deck, you need the following accessories: - Car connecting pack - Car battery cord You cannot use the car mount plate for this CD player. Refer to the instruction manual of each accessory for details. Notes - Do not put the CD player on the dashboard. - Do not leave the CD player in a car parked under sunlight. - If the sound is distorted, press SOUND until the BASS indication disappears from the display. - Use a Sony car connecting pack for reducing noise. - Use only the car battery cord listed in the optional accessories. If you use any other car battery cord, smoke, fire or malfunction may occur. Switched ignition function (when using the car battery cord) With this feature, your CD player stops automatically when you turn off the engine of the car. (This function is not possible with some cars depending on the model.) Using the supplied remote control You can use the remote control as the wired remote control. * Automatic Music Sensor **When you are not using the remote control, slide HOLD in the direction of the arrow to prevent any accidental operations. To unlock, slide HOLD back. BPower Sources Using the rechargeable batteries Charge the rechargeable batteries before using them for the first time. You can use only the following rechargeable batteries for your CD player. - NC-WMAA - NH-WM2AA 1 Open the battery compartment lid. 2 Insert two rechargeable batteries by matching the 3 to the diagram in the battery compartment and close the lid. 3 Connect the AC power adaptor to the DC IN 4.5 V jack of your CD player and an AC outlet, then press x/CHG to start charging. The CD player charges the batteries. The CHG indicator turns on in the display, and the indicator sections of light up in succession. When the batteries are completely charged, the CHG and indicators turn off. If you press x/CHG after the charge has already been completed, the indicator flashes and Full appears in the display. 4 Disconnect the AC power adaptor. To remove the rechargeable batteries Remove the batteries as illustrated below. BAdditional Information Precautions On safety- Should any solid objects or liquid fall into the unit, unplug it and have it checked by qualified personnel before operating it any further. - Do not put any foreign objects in the DC IN 4.5 V (external power input) jack. On power sources- When you are not using the CD player for a long time, disconnect all power sources from the player. On the AC power adaptor- Use only the supplied AC power adaptor. If your player is not supplied with it, use AC- E45HG AC power adaptor. Do not use any other AC power adaptor. - To unplug the AC power adaptor from the wall outlet, grasp the adaptor itself, do not pull its cord. On rechargeable batteries and dry batteries - Do not charge the dry batteries. - Do not throw the batteries into fire. - Do not carry the batteries with coins or other metallic objects. It can generate heat if the positive and negative terminals of the battery are accidentally contacted by a metallic object. - Do not mix rechargeable batteries with dry batteries. - Do not mix new batteries with old ones. - Do not use different types of batteries together. - When the batteries are not to be used for a long time, remove them. - If battery leakage occurs, wipe off any deposit in the battery compartment, and install new batteries. In case the deposit adheres to you, wash it off thoroughly. On the CD player- Keep the lens of the CD player clean and do not touch it. If you do so, the lens may be damaged and the player will not operate properly. - Do not put any heavy object on top of the player. The unit and the CD may be damaged. - Do not leave the CD player in a location near heat sources, or in a place subject to direct sunlight, excessive dust or sand, moisture, rain, mechanical shock, unleveled surface, or in a car with its windows closed. - If the CD player causes interference to radio or television reception, turn off the CD player or move it away from the radio or television. - Do not wrap the CD player in a cloth or blanket during use as it may cause malfunction or serious accidents. - Discs with non-standard shapes (e.g., heart, square, star) cannot be played on this CD player. Attempting to do so may damage the CD player. Do not use such discs. On headphones/earphonesRoad safetyDo not use headphones/earphones while driving, cycling, or operating any motorized vehicle. It may create a traffic hazard and is illegal in some areas. It can also be potentially dangerous to play your headsets at high volume while walking, especially at pedestrian crossings. You should exercise extreme caution or discontinue use in potentially hazardous situations. Preventing hearing damageAvoid using headphones/earphones at high volume. Hearing experts advise against continuous, loud and extended play. If you experience a ringing in your ears, reduce volume or discontinue use. Caring for othersKeep the volume at a moderate level. This will allow you to hear outside sounds and to be considerate to the people around you. Maintenance To clean the casingUse a soft cloth slightly moistened in water or a mild detergent solution. Do not use alcohol, benzine or thinner. Troubleshooting Should any problem persist after you have made these checks, consult your nearest Sony dealer. The CD does not play or no dlSC appears in the display though a CD is placed in the unit. cThe CD is dirty or defective. cInsert the CD with the label side up. cMoisture condensation has occurred. Leave the unit aside for several hours until the moisture evaporates. cClose the lid of the unit and the battery compartment firmly. cMake sure the batteries are inserted correctly. cConnect the AC power adaptor to a wall outlet securely. cThe CD-R was not finalized. Finalize the CD-R with the recording device. cThere is a problem with the quality of the CD-R, recording device, or application software. When you press > N, 00 appears in the display for a moment, and disappears. The CD does not play. cRechargeable batteries are used up completely. Charge the batteries. cReplace the batteries with new LR6 (size AA) alkaline batteries. No sound, or noise is heard. cConnect the plugs firmly. cPlugs are dirty. Clean the plugs with a dry soft cloth periodically. Hl dc ln appears in the display. cUse only the supplied AC power adaptor or AC power adaptor AC-E45HG (not supplied). Hold appears in the display when you press a button. cThe buttons are locked. Slide HOLD back. The indication appears in the display when you press a button. cRechargeable batteries are used up completely. Charge the batteries. cReplace the batteries with new LR6 (size AA) alkaline batteries. The battery life is short. cManganese batteries are used. Use alkaline batteries. cReplace the batteries with new ones. The volume is limited to a certain level even if you attempt to turn it up. cAVLS function keeps down the volume. Hold down SOUND until AVLS disappears from the display. Playback starts from the point you stopped. cThe resume function is working. Open the lid of the CD player; or remove all power sources, then insert the batteries or connect the AC power adaptor again. Specifications CD playerSystem Compact disc digital audio system Laser diode properties Material: GaAlAs Wavelength: λ = 780 nm Emission duration: Continuous Laser output: Less than 44.6 µW (This output is the value measured at a distance of 200 mm from the objective lens surface on the optical pick-up block with 7 mm aperture. ) Error correction Sony Super Strategy Cross Interleave Reed Solomon Code D-A conversion 1-bit quartz time-axis control Frequency response 20 - 20 000 Hz +1 –3 dB (measured by EIAJ CP- 307) Output (at 4.5 V input level) Headphones (stereo minijack) Approx. 12 mW + approx. 12 mW at 16 Ω GeneralPower requirements For the area code of the model you purchased, check the upper left side of the bar code on the package. - Two Sony NC-WMAA rechargeable batteries: 2.4 V DC - Sony NH-WM2AA rechargeable batteries: 2.4 V DC - Two LR6 (size AA) batteries: 3 V DC - AC power adaptor (DC IN 4.5 V jack): U/U2/CA2/E92/MX2/TW2/BR3 model: 120 V, 60 Hz CED/CEX/CET/CEW/CE7/EE/EE1/ E13/G5/G6/G7/G8/BR1 model: 220 - 230 V, 50/60 Hz CEK/3CE7 model: 230 - 240 V, 50 Hz AU2 model: 240 V, 50 Hz JE.W/E33/EA3 model: 100 - 240 V, 50/60 Hz HK2 model: 220 V, 50/60 Hz AR1/CNA model: 220 V, 50 Hz Dimensions (w/h/d) (without projecting parts and controls) Approx. 130.0 × 26.3 × 150.5 mm (5 1⁄8 × 1 1⁄16 × 6 in.) Mass (excluding accessories) Approx. 205 g (7.3 oz) Operating temperature 5°C - 35°C (41°F - 95°F) Supplied accessoriesFor the area code of the model you purchased, check the upper left side of the bar code on the package. AC power adaptor (1) Headphones with remote control (1) Rechargeable batteries (2) Battery carrying case (1) Design and specifications are subject to change without notice. For US customers AC power adaptor supplied is not intended to be serviced. Should the AC power adaptor cease to function in its intended manner, during the warranty period, the adaptor should be returned to your nearest Sony Service Center or Sony Authorized Repair Center for replacement, or after warranty period, it should be discarded.Stereo miniplug Micro plug Polarity of the plug r aaaa aaaa r r r r When to charge the rechargeable batteries You can check the remaining power of the batteries in the display. Battery power is full. Battery power is getting low. Battery power is low. Lo batt* Batteries are depleted. *Beep sounds. To keep the original battery capacity for a long time, charge the batteries only when they are completely depleted. Notes - The indicator sections of roughly shows the remaining battery power. One section does not always indicate one-fourth of the battery power. - Depending on operating conditions, the indicator sections of may increase or decrease. When to replace the rechargeable batteries If the battery life becomes shorter by about half, replace the batteries with new rechargeable batteries. Note on the rechargeable batteriesIf the battery is new or has not been used for a long time, it may not be charged completely until you charge and discharge it several times. Note on carrying the rechargeable batteries Use the supplied battery carrying case to prevent unexpected heat. If the rechargeable batteries and the metallic objects are contacted, heat or fire may occur due to a short circuit. To attach the battery compartment lid If the battery compartment lid is detached by an accidental drop, excessive force, etc., attach it as illustrated below.r aaaa aaaa r r r r Using the dry batteries Use only the following dry battery type for your CD player: - LR6 (size AA) alkaline batteries Note Be sure to remove the AC power adaptor when using the dry batteries. 1 Open the lid of the battery compartment. 2 Insert two LR6 (size AA) alkaline batteries by matching the 3 to the diagram in the battery compartment. To remove the batteriesRemove the batteries in the same way as rechargeable batteries. When to replace the batteriesYou can check the remaining power of the batteries in the display. Battery power is full. Battery power is getting low. Battery power is low. Lo batt* Batteries are depleted. *Beep sounds. When the batteries are depleted, replace both batteries with new ones. Battery life (approx. hours)(EIAJ*)Battery life varies depending on how the player is used. ESP OFF ESP ON Two NC-WMAA 8 8 (charged for about 3 hours**) NH-WM2AA 14.5 14 (charged for about 8 hours**) Two Sony alkaline 25 24 batteries LR6(SG) * Measured value by the standard of EIAJ (Electronic Industries Association of Japan). (When the unit is used on a flat and stable place.) ** Charging time varies depending on how the rechargeable battery is used. (rear) x/CHG button to an AC outletDC IN 4.5 V AC power adaptor Optional accessories Car connecting pack CPA-9C Car battery cord with car connecting pack DCC-E34CP Car battery cord DCC-E345 Active speaker system SRS-A21 Connecting cord RK-G129, RK-G136 AC power adaptor AC-E45HG Rechargeable batteries NH-WM2AA Stereo headphones* MDR-EX70LP * When using optional headphones, use only headphones with stereo miniplugs. You cannot use headphones with micro plugs. Your dealer may not handle some of the above listed accessories. Please ask the dealer for detailed information about the accessories in your country. This warranty is valid only in the United States. VOL (volume) +/–HOLD** . (AMS*/ search) x (stop) N (play)-> (AMS*/search)
