Ver 1.0 1998. 04 SERVICE MANUAL SUPPLEMENT - 1 File this Supplement with the Service Manual. (ECN-CD850102) US Model D-171C Subject : r A MODEL IN WHITE COLOR HAS BEEN ADDED The color of D-171C was originally silver, but a model in white color has been added. Consequently, only added parts are listed in this Supplement-1. For other information, please refer to the D-171C service manual (9-923-313- 11), D-170AN/171/171V/172CK/173/175 service manual (9-923-149-11), Supplement-1 (9-923-149-81) and Supplement-2 (9-923-149-82) previously issued. Ref. No. Part No. Description 5 X-4950-144-1 CABINET (UPPER) SUB ASSY (WHITE) 8 X-4950-104-1 LID ASSY, UPPER (WHITE) 15 4-975-821-11 BUTTON (CHARGE) (WHITE) 16 X-4950-145-1 CABINET (LOWER) SUB ASSY (WHITE) 17 4-986-055-01 LID, BATTERY CASE (WHITE) 19 4-984-751-01 KNOB (AVLS) 21 4-984-747-01 KNOB (H-R) EXPLODED VIEWS (D-170AN/171/171V/172CK/173/175 Service Manual See page 27) r ADDED PARTS LIST 9-923-313-81 Sony Corporation Personal A&V Products Company 98D0218-1 Printed in Japan © 1998.4 Published by Quality Engineering Dept. (Shibaura)
