CXS-27FSQ 2 PARTS LIST Ref. No. Part No. Description Remark ACCESSORIES ************ 1-826-276-11 SPEAKER (16 cm) (XS-GF1622X) 1-826-313-11 SPEAKER (6X9 inch) (Lch) (XS-GF6932X) 1-826-313-21 SPEAKER (6X9 inch) (Rch) (XS-GF6932X) 2-661-994-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH, SPANISH,TRADITIONAL CHINESE, SIMPLIFIED CHINESE,ARABIC,PERSIAN, INDONESIAN,THAI,MALAY,KOREAN) (XS-GF6932) 3-275-624-12 MANUAL, INSTRUCTION (ENGLISH,SPANISH, PERSIAN) (CXS-27FSQ) ************************************************************* PARTS FOR INSTALLATION AND CONNECTIONS ************************************** 1 2-679-667-01 TEMPLATE 2 A-1101-503-A SCREW ASSY 3 1-574-318-71 CORD, SPEAKER (Lch) (WHITE) 3 1-574-318-81 CORD, SPEAKER (Rch) (GRAY) 4 X-2102-564-1 NET ASSY, GRILLE 5 2-661-995-01 PATTERN, PAPER 6 1-574-318-71 CORD, SPEAKER (Lch) (WHITE) 6 1-574-318-81 CORD, SPEAKER (Rch) (GRAY) 7 3-240-189-21 SCREW, SPECIAL 8 3-392-841-02 NUT, SPEED 9 2-661-996-01 FRAME, GRILLE 10 X-2103-320-1 NET ASSY, GRILLE 12 34 TEMPLATE × 1 SPEAKER CORD × 2 SCREW ASSY GRILLE NET ASSY GRILLE FRAME × 2PUNCHING NET × 2 SPEED NUT × 8 SPECIAL SCREW × 8 XS-GF1622X: XS-GF6932X: 5 6 8 9 10 7 PAPER PATTERN × 1 GRILLE FRAME× 2GRILLE NET ASSY × 2 SPECIAL SCREW × 8 SPEED NUT × 8 SPEAKER CORD × 2
Page 2
CXS-27FSQ 3 MEMO
