Sony cfs b 5 l mk2 schematic
This is the 2 pages manual for sony cfs b 5 l mk2 schematic.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony cfs b 5 l mk2 schematic (Ocr-read)
Page 1
Ð 19 ÐÐ 20 Ð 5-6. SCHEMATIC DIAGRAM Ñ MAIN SECTION Ñ CFS-B5LMK2 Note: ¥ All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. ¥C: panel designation. Note:The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified.¥U: B+ Line. ¥ Total current is measured with no cassette installed. ¥ Power voltage is dc 9 V and fed with regulated dc power supply from battery terminal. ¥ Voltage and waveforms are dc with respect to ground under no-signal (detuned) conditions. no mark : FM < > : PB << >> : REC¥ Voltages are taken with a VOM (Input impedance 10 MW). Voltage variations may be noted due to normal produc- tion tolerances. ¥ Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. ¥ Circled numbers refer to waveforms. ¥ Signal path. F: FM E: PB a: REC (Page 16) T301 ¥ Waveform (MODE:REC) 1 35Vp-p 15mS
