Sony cfs 710 l service manual

Page 2

CFS-71OL

TABLE OF CONTENTS

Section M Page
1. GENERAL
1-1. Location and Function of Controls ----------- 3
2. DISASSEMBLY
2-1. Removal of Cassette Lid Assy 4
2-2. Dial Pointer Setting - - ~ ' 4
3. MECHANICAL ADJUSTMENTS ~~~~~~~~~ S
4. ELECTRICAL ADJUSTMENTS
4-1. Tape Recorder Section ~~~~~~~~~~~~~~~~~~~~ 6
4.2. Radio Section ............................ 3
DIAGRAMS
5-1. Discrete Board Type Printed
Wiring Boards (Except CIS) ~~~~~~~~~~~~~~~ 14
5-2. Discrete Board Type Tuner Section
Schematic Diagram (Except CIS) --------- 17

Section M Page

5-3. Discrete Board Type Audio Section

Schematic Diagrams (Except CIS) ~~~~~~~~~~ 19
5-4. Printed Resistor Circuit Board Type

Printed Wiring Boards (Except CIS) -------- 21
55. Printed Resistor Circuit Board Type Tuner

Section Schematic Diagram (Except CIS) ~~~~~ 25
5-6. Printed Resistor Circuit Board Type Audio

Section Schematic Diagrams (Except CIS) . - 27
5-7. Discrete Board Type

Printed Wiring Boards (CIS Model Only) ooooo 30
5-8. Discrete Board Type Tuner Section

Schematic Diagram (CIS Model Only) ------- 33
5-9. Discrete Board Type Audio Section

Schematic Diagrams (CIS Model Only) """" 35
6. EXPLODED VIEWS .................... 39
7. ELECTRICAL PARTS LIST ----------- 46

MODEL IDENTIFICATION
- Specification Label ~

SONXo

MODEL NOT CFD-710L

4"-

-'- AEP, G, IT, EE, CIS model 2 AC: 220V ~50HZ 22W
RADIO CASSETTE-CORDER UK mode.

: AC: 240V ~50Hz 40W
(G model : Germany model)
(IT model 2 Italian model)
(EE model : East European model)
(CIS model :Common Independent States model)

SAFETY-RELATED COMPONENT WARNINGI!

COMPONENTS IDENTIFIED BY MARK & OR DOTTED
LINE WITH MARK & ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-

LISHED BY SONY.
