E Model

(:3

This set is the almost same as CFS-l 1008.
Refer to CPS-11008 Service Manual previously issued for
the information of this set.
The contents which differ from those in CPS-11005 are
mentioned in this Service Manual.

SPECIFICATIONS
Tuner frequency range:
FM MW SW
Saudi Arabia
mode, 87.6-107MH2

E, UAE model 87.6-108MHZ

530 - 1,605 kHz

SW1: 2.3 - 7 MHz
- 22 MHz

Antennas:
MW
Frequency response:

FM/SW: Telescopic
: Built»in ferrite bar

80 - 8,000 Hz (Type 1)

Speakers:

Two way: tweeter 2cm (/1 in.) die.
full range 12cm (4% in.) die.

Impedance: (30th

Nominal power handling capacity:
Maximum power handling capacity:15W

Maximum power outputs:

15W (75W+ 75W)

Inputs: Two external microphone input jacks

(miniiack)
sensitivity 0.775 mV for low impedance
microphone

UAE. United Arab Emirates model

Model Name Using CFS-1 0108

Similar Mechanism Set CPS-11008

Tape Transport Mechanism Type MF-l 1 00-780
Outputs: Headphones jack (stereo minijack)

for 8 -300 ohm impedance headphones
Speaker connectors for supplied Bohm
impedance speakers only
Power requirements:
110 - 120 V, 220 - 240 V AC adjustable,
50/60 Hz 9V DC, six R20 (Size D) batteries
Power consumption:

30W
Battery life:
Batteries FM recording
Sony SUM-1 (Ns) approx. 16hours
Sony AMI alkaline approxl 25h0urs
Dimensions: Approx. 661 x 179 x 183 mm (w/h/d)
(261/3 x 71/3 x 71/4 inches)
incl. speakers, projecting parts and controls,
not incl. handle
Weight: Approx. 5.6 kg (11 lb 14 oz) incl. speakers,

batteries

Accessory supplied AC power cord (1)
