Sony cfd s 22 s 32

This is the 48 pages manual for sony cfd s 22 s 32.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 48
sony cfd s 22 s 32

Extracted text from sony cfd s 22 s 32 (Ocr-read)


Page 2

– 3 – TABLE OF CONTENTS 1. SERVICING NOTES ......................................................... 4 2. GENERAL Location of controls ................................................................. 5 Adjusting the sound emphasis (MEGA BASS/TONE) ........... 5 Playing a CD ........................................................................... 6 Listening to the radio ............................................................... 6 Playing a tape .......................................................................... 7 Recording ................................................................................ 7 3. DISASSEMBLY 3-1. Cabinet (Front) Sub Assy .................................................... 8 3-2. Wires ................................................................................... 9 3-3. Secondary Board, Power Board .......................................... 9 3-4. Tuner Board ....................................................................... 10 3-5. Cabinet (Upper) Block Assy ............................................. 10 3-6. Main Board ....................................................................... 11 3-7. CD Mechanism Block ....................................................... 11 3-8. Tape Mechanism Block ..................................................... 12 3-9. Holder Assy, Cassette ........................................................ 12 3-10. TC Board ........................................................................... 13 4. MECHANICAL ADJUSTMENTS ............................... 14 5. ELECTRICAL ADJUSTMENTS Tape Section .......................................................................... 14 Tuner Section ......................................................................... 15 CD Section ............................................................................ 16 6. DIAGRAMS 6-1. IC Pin Description ............................................................. 17 6-2. Circuit Boards Location .................................................... 18 6-3. Block Diagram – CD Section – ......................................... 19 6-4. Block Diagram – Main Section – ...................................... 21 6-5. Printed Wiring Board – Tuner Section – ........................... 23 6-6. Schematic Diagram – Tuner Section – .............................. 25 6-7. Printed Wiring Board – CD Section – ............................... 27 6-8. Schematic Diagram – CD Section – .................................. 29 6-9. Schematic Diagram – TC Section – .................................. 31 6-10. Printed Wiring Boards – Main Section – .......................... 33 6-11. Schematic Diagram – Main Section (1/2) – ...................... 35 6-12. Schematic Diagram – Main Section (2/2) – ...................... 37 6-13. Printed Wiring Board – Control Section – ........................ 39 6-14. Schematic Diagram – Control Section – ........................... 41 6-15. Printed Wiring Boards – Power Supply Section – ............ 43 6-16. Schematic Diagram – Power Supply Section – ................. 45 7. EXPLODED VIEWS 7-1. Cabinet (Front) Section ..................................................... 50 7-2. Cabinet (Rear) Section ...................................................... 51 7-3. Cabinet (Upper) Section .................................................... 52 7-4. Tape Mechanism Section-1 ............................................... 53 7-5. Tape Mechanism Section-2 ............................................... 54 7-6. Optical Pick-up Section .................................................... 55 8. ELECTRICAL PARTS LIST ......................................... 56 To Exposed Metal Parts on Set 0.15µF 1.5k Ω AC voltmeter (0.75V) Earth Ground Fig. A. Using an AC voltmeter to check AC leakage. SAFETY CHECK-OUT After correcting the original service problem, perform the following safety check before releasing the set to the customer: Check the antenna terminals, metal trim, metallized knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below. LEAKAGE TEST The AC leakage from any exposed metal part to earth ground and from all exposed metal parts to any exposed metal part having a return to chassis, must not exceed 0.5 mA (500 microamperes). Leakage current can be measured by any one of three methods. 1. A commercial leakage tester, such as the Simpson 229 or RCA WT-540A. Follow the manufacturers instructions to use these instruments. 2. A battery-operated AC milliammeter. The Data Precision 245 digital multimeter is suitable for this job. 3. Measuring the voltage drop across a resistor by means of a VOM or battery-operated AC voltmeter. The limit indication is 0.75 V, so analog meters must have an accurate low-voltage scale. The Simpson 250 and Sanwa SH-63Trd are examples of a passive VOM that is suitable. Nearly all battery operated digital multimeters that have a 2V AC range are suitable. (See Fig. A)
