Sony cdx l 410 service manual
This is the 40 pages manual for sony cdx l 410 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony cdx l 410 service manual (Ocr-read)
Page 1
2 SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT The laser diode in the optical pick-up block may suffer electrostatic breakdown because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic breakdown and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. NOTES ON LASER DIODE EMISSION CHECK The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pick- up block. Therefore, when checking the laser diode emission, ob- serve from more than 30 cm away from the objective lens. Notes on Chip Component Replacement -Never reuse a disconnected chip component. -Notice that the minus side of a tantalum capacitor may be dam- aged by heat. SERVICE NOTES This label is located on the bottom of the chassis. This label is located on the drive units internal chassis. When replacing the chassis (T.U) of mechanism deck which have the CAUTION LABEL attached, please be sure to put a new LABEL (OP CAUTION) (3-223-913-01) to the chassis (T.U). CDX-L410 CLASS 1 LASER PRODUCT VIEW DIRECTLY WITH OPTICAL INSTRUMENTSDO NOT STARE INTO BEAM OR INVISIBLE LASER RADIATION WHEN OPEN CAUTION TEST DISCS This set can playback CD-R and CD-ROM discs. The following test discs should be used to check the capability: CD-R test disc TCD-R082LMT (Part No. J-2501-063-1) CD-RW test disc TCD-W082L (Part No. J-2501-063-2)
Page 2
3 TABLE OF CONTENTS 1. GENERAL Location of controls ................................................................. 4 Notes on CD-R/CD-RW discs ................................................. 4 Connections ............................................................................. 5 2. DISASSEMBLY 2-1. Sub Panel Assy .................................................................... 6 2-2. CD Mechanism Block ......................................................... 7 2-3. Main Board ......................................................................... 7 2-4. Heat Sink ............................................................................. 8 2-5. Chassis (T.U) Assy .............................................................. 8 2-6. Disc in Board ...................................................................... 9 2-7. Servo Board ......................................................................... 9 2-8. Arm Roller Assy ................................................................ 10 2-9. Chassis (OP) Assy ............................................................. 10 2-10. Optical Pick-up Block ....................................................... 11 3. DIAGRAMS 3-1. IC Pin Description ............................................................. 12 3-2. Circuit Boards Location .................................................... 143-3. Block Diagram –CD Section–........................................... 15 3-4. Block Diagram –Tuner Section–....................................... 16 3-5. Block Diagram –Display Section–.................................... 17 3-6. Printed Wiring Boards –CD Mechanism Section–............ 18 3-7. Schematic Diagram –CD Mechanism Section–................ 20 3-8. Printed Wiring Board –Main Section–.............................. 21 3-9. Schematic Diagram –Main Section (1/2)–........................ 22 3-10. Schematic Diagram –Main Section (2/2)–........................ 23 3-11. Printed Wiring Board –Key Section–................................ 24 3-12. Schematic Diagram –Key Section–................................... 25 4. EXPLODED VIEWS 4-1. Chassis Section ................................................................. 28 4-2. Front panel Section ........................................................... 29 4-3. CD Mechanism Section (1) ............................................... 30 4-4. CD Mechanism Section (2) ............................................... 31 4-5. CD Mechanism Section (3) ............................................... 32 5. ELECTRICAL PARTS LIST ......................................... 33 MAIN BOARD CNP301 J-2502-011-1SERVO BOARD CN1 EXTENSION CABLE AND SERVICE POSITION When repairing or servicing this set, connect the jig (extension cable) as shown below. -Connect the MAIN board (CNP301) and the SERVO board (CN1) with the extension cable (Part No. J-2502-011-1). CDX-L410
