2 CDX-CA650X/CA660X/CA690X SERVICE NOTES If the optical pick-up block is defective, please replace the whole optical pick-up block. Never turn the semi-fixed resistor located at the side of optical pick-up block. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT The laser diode in the optical pick-up block may suffer electrostatic breakdown because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic breakdown and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. NOTES ON LASER DIODE EMISSION CHECK The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pick- up block. Therefore, when checking the laser diode emission, ob- serve from more than 30 cm away from the objective lens. Notes on Chip Component Replacement -Never reuse a disconnected chip component. -Notice that the minus side of a tantalum capacitor may be dam- aged by heat. TABLE OF CONTENTS 1. GENERAL Location of controls ................................................................. 3 Getting Started ......................................................................... 3 CD Player ................................................................................ 4 Radio ....................................................................................... 5 Other Functions ....................................................................... 6 Connection Diagram ................................................................ 7 2. DISASSEMBLY 2-1. Sub Panel (CD) Assy ........................................................... 8 2-2. CD Mechanism Block ......................................................... 8 2-3. Main Board ......................................................................... 8 2-4. Heat Sink (Main) ................................................................. 9 2-5. Chassis (T) Sub Assy .......................................................... 9 2-6. Lever Section .................................................................... 10 2-7. Servo Board ....................................................................... 10 2-8. Arm Roller Assy ................................................................ 11 2-9. Floating Block ................................................................... 11 2-10. Optical Pick-up Block ....................................................... 12 3. DIAGRAMS 3-1. IC Pin Descriptions ........................................................... 13 3-2. Block Diagram –CD Section– ........................................... 15 3-3. Block Diagram –Tuner Section– ....................................... 16 3-4. Block Diagram –Display Section– .................................... 17 3-5. Circuit Boards Location .................................................... 17 3-6. Printed Wiring Boards –CD Mechanism Section– ............ 18 3-7. Schematic Diagram –CD Mechanism Section– ................ 20 3-8. Printed Wiring Boards –Main Section– ............................ 21 3-9. Schematic Diagram –Main Section (1/2)– ........................ 22 3-10. Schematic Diagram –Main Section (2/2)– ........................ 23 3-11. Printed Wiring Board –Relay Section– ............................. 24 3-12. Schematic Diagram –Relay Section– ................................ 25 3-13. Schematic Diagram –Display Section– ............................. 26 3-14. Printed Wiring Board –Display Section– .......................... 27 4. EXPLODED VIEWS 4-1. Chassis Section ................................................................. 30 4-2. Front panel Section ........................................................... 31 4-3. CD Mechanism Section (1) ............................................... 32 4-4. CD Mechanism Section (2) ............................................... 33 4-5. CD Mechanism Section (3) ............................................... 34 5. ELECTRICAL PARTS LIST ........................................ 35 optical pick-up bloc k semi-fixed resistor SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. ATTENTION AU COMPOSANT AYANT RAPPORT À LA SÉCURITÉ!! LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0 SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.
Page 2
3 CDX-CA650X/CA660X/CA690X SECTION 1 GENERAL This section is extracted from instruction manual.
