Sony cdx 4000 x service manual

Page 1

2 TABLE OF CONTENTS 1. GENERAL Location of controls ................................................................. 3 Getting Started ......................................................................... 3 Setting the clock ...................................................................... 3 CD Player ................................................................................ 3 Radio ....................................................................................... 4 Other Functions ....................................................................... 5 Connections ............................................................................. 6 2. DISASSEMBLY 2-1. Sub Panel (CD) Assy ........................................................... 8 2-2. CD Mechanism Block ......................................................... 8 2-3. Main Board ......................................................................... 9 2-4. Heat Sink ............................................................................. 9 2-5. Chassis (T) Sub Assy ........................................................ 10 2-6. Lever Section ..................................................................... 10 2-7. Servo Board ....................................................................... 11 2-8. Shaft Roller Assy .............................................................. 11 2-9. Floating Block Assy .......................................................... 12 2-10. Optical Pick-up Block ....................................................... 12 3. DIAGRAMS 3-1. IC Pin Descriptions ........................................................... 13 3-2. Block Diagram –CD Section– ........................................... 19 3-3. Block Diagram –Tuner Section– ....................................... 20 3-4. Block Diagram –Display Section– .................................... 21 3-5. Circuit Boards Location .................................................... 21 3-6. Printed Wiring Boards –CD Mechanism Section– ............ 22 3-7. Schematic Diagram –CD Mechanism Section (1/2)– ....... 24 3-8. Schematic Diagram –CD Mechanism Section (2/2)– ....... 25 3-9. Schematic Diagram –Main Section (1/2)– ........................ 26 3-10. Schematic Diagram –Main Section (2/2)– ........................ 27 3-11. Printed Wiring Board –Main Section– .............................. 28 3-12. Printed Wiring Board –Relay Section– ............................. 29 3-13. Schematic Diagram –Relay Section– ................................ 30 3-14. Schematic Diagram –Display Section– ............................. 31 3-15. Printed Wiring Board –Display Section– .......................... 32 3-16. IC Block Diagrams ............................................................ 33 4. EXPLODED VIEWS 4-1. Chassis Section ................................................................. 36 4-2. Front Panel Section ........................................................... 37 4-3. CD Mechanism Section (1) ............................................... 38 4-4. CD Mechanism Section (2) ............................................... 39 4-5. CD Mechanism Section (3) ............................................... 40 5. ELECTRICAL PARTS LIST ........................................ 41 SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. SERVICE NOTES NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT The laser diode in the optical pick-up block may suffer electrostatic breakdown because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic breakdown and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. NOTES ON LASER DIODE EMISSION CHECK The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pick- up block. Therefore, when checking the laser diode emission, ob- serve from more than 30 cm away from the objective lens. Notes on Chip Component Replacement -Never reuse a disconnected chip component. -Notice that the minus side of a tantalum capacitor may be dam- aged by heat. ATTENTION AU COMPOSANT AYANT RAPPORT À LA SÉCURITÉ!! LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0 SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY. General Outputs Audio outputs Power antenna relay control lead Power amplifier control lead Telephone ATT control lead Tone controls Bass ±9 dB at 100 Hz Treble ±9 dB at 10 kHz Power requirements 12 V DC car battery (negative ground) Dimensions Approx. 178 × 50 × 183 mm (7 1/8 × 2 × 7 1/4 in.) (w/h/d) Mounting dimensions Approx. 182 × 53 × 162 mm (7 1/4 × 2 1/8 × 6 1/2 in.) (w/h/d) Mass Approx. 1.2 kg (2 lb. 10 oz.) Supplied accessories Parts for installation and connections (1 set) Front panel case (1) Design and specifications are subject to change without notice. Ver 1.1 2000. 08 If the optical pick-up block is defective, please replace the whole optical pick-up block. Never turn the semi-fixed resistor located at the side of optical pick-up block. optical pick-up bloc k semi-fixed resistor CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
