Sony cdp m205 cdp m305
This is the 23 pages manual for sony cdp m205 cdp m305.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony cdp m205 cdp m305 (Ocr-read)
Page 1
Ð 2 Ð SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. MODEL NO. CDP-M205 CDP-M305 COMPACT DISC PLAYER SERIAL NO. MADE IN JAPAN AEP, UK model : AC : 220Ð230V Ú50/60Hz 10W E model : AC : 110Ð120V, 220Ð240V Ú Adjustable 50/60Hz 10W Specifications ........................................................................... 1 1. GENERAL Location and Function of Controls .................................... 3 2. SERVICING NOTE.......................................................... 4 3. DISASSEMBLY............................................................... 5 4. ELECTRICAL ADJUSTMENTS................................... 6 5. DIAGRAMS 5-1. IC Pin Function ........................................................... 7 5-2. Printed Wiring Boards Ð BD Section Ð ...................... 11 5-3. Schematic Diagram Ð BD Section Ð ......................... 13 5-4. Schematic Diagram Ð Main Section Ð ...................... 17 5-5. Printed Wiring Boards Ð Main Section Ð .................. 21 6. EXPLODED VIEWS 6-1. Main Section ............................................................. 26 6-2. CD Block Section ..................................................... 27 6-3. Optical Pick-up Block Section (BU-5BD29B) ......... 28 7. ELECTRICAL PARTS LIST........................................ 29 TABLE OF CONTENTS WARNING To prevent fire or shock hazard, do not expose the unit to rain on moisture. To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only. The following caution label is located inside of the unit. This appliance is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT MARKING is located on the rear exterior. Laser component in this product is capable of emitting radiation exceeding the limit for Class 1. MODEL IDENTIFICATION
Page 2
Ð 3 Ð SECTION 1 GENERAL LOCATION AND FUNCTION OF CONTROLS This section is extracted from instruction manual. 123456!¤78 !° !¢ !£ !ª !Á 0 9 9P(PAUSE) button 0á(PLAY) button !ÁDISPLAY window !ªREMOTE senser (CDP-M305 only) !£PEAK SEARCH button !¢REPEAT button !°TIME button !¤VOLTAGE selector (Singapore model) 1POWER switch 2CONTINUE button 3SHUFFLE button 4PROGRAM button 5DISK tray 6OPEN/CLOSE button 70/) (MANUAL SEARCH) buttons =/+(AMS : AUTOMATIC MUSIC SENSOR) buttons 8p(STOP) button 1 2 3 4 5 6 7 8 !° !¢ !£ !ª !Á 0 9 9=/+(AMS : AUTOMATIC MUSIC SENSOR) buttons 0((PLAY) button !ÁREPEAT button !ªTIME button !£>10 (OVER 10) button !¢NUMBER buttons !°CONTINUE button 1SHUFFLE button 2PROGRAM button 3CLEAR button 4CHECK button 5FADER button 6p(STOP) button 7P(PAUSE) button 80/)(MANUAL SEARCH) buttons Front Panel Remote Commander (CDP-M305 only)
