CDP-C'IO

US Model
Canadian Model
AEP Model
UK Model

E Model

secnom
1-1. MOUNTING DIAGRAMS
_POWER_ DIAGRAMS
3 I 4 I 5 I 6 I

SPECIFICATIONS

COMPACT DISC PLAYER GDP-010
System Compact disc digital audio system
Frequency response
2 Hz 20,000 Hz ( :?2 dB)
Signal to noise ratio
More than 98 dB
Dynamic range More than 95 dB
Harmonic distortion
Less than 0.003% (at 1 kHz)
Channel separation

More than 90 dB
Wow and flutter Below measurable limit
Outputs Fixed line outputs (phonojacks)

Output level 2 Vrms (at MSB)

Load impedance over 10 kilohms
Variable line outputs (phono jacks)

Output level 0 Vrms , 2 V rms (at MSB)

Load impedance over 50 kilohms
Headphones (phone jack)

28 mW at 32 ohms

General
Power requirements
Model for European countries:
220 V AC, 50 Hz
Model for United Kingdom:
240 V AC, 50 Hz
Model for other countries:
120, 220 or 240 V AC adjustable,

50/60 Hz
Powerconsumption
17 W
Dimensions Approx. 430 X115 x 340 mm (w/hld)

(17 X 45/9 x 131/2 inches)
incl. projecting parts and controls
Weight Approx. 7.5 kg (16 lbs 9 oz), net

Muflfil-MJ

REMOTE COMMANDER RM-D110
Remote control system
Infrared control
Power requirements
3 V dc with two batteries size AA
(IEC desrgnation R6)
Dimensions Approx. 67 x 20 X 175 mm (w/hld)
(23/4 x /15 x 7 Inches)
incl, projecting parts and controls
Weight Approx. 145 g (5.1 oz)
incl. batteries

Note
This appliance contorms with EEC Directives 76/889 and 82/499
regarding interference suppression,

SUPPLIED ACCESSORIES
Audio signal connecting cord
(phono plug x 2 *-> phono plug x 2) (1)
Remote commander(1)
Disc magazine (1)
CD booklet holder (1)
Sony New Super batteries SUM-3 (NS) (2)

Design and specrfications subject to change without notice.

summer nisc PLAYER
SONY;

Elli

1-597- 095 '11
1-620-698-11 SONY
cum-140x
