LIMITED FIVE YEAR WARRANTY Sonic Frontiers, Inc. warrants to the purchaser that each UltraJitterbug is free of manufacturing defects for a period of five (5) years from the date of purchase. To receive this warranty, the original purchaser must mail to Sonic Frontiers, within thirty (30) days from date of purchase, the enclosed Warranty Registration Card completed. Sonic Frontiers, Inc. will then validate the warranty to the original purchaser. This warranty is subject to the following condi- tions and limitations:1.Warranty applies only to the original purchaser. 2 .This warranty is void and inapplicable if the product has been handled other than in accordance with the instructions in this Owners Manual, abused or misused, damaged by accident or neglect or in being transported, or the defect is due to the product being tampered with, modified or repaired by anyone other than Sonic Frontiers, Inc. or an authorized Sonic Frontiers repair depot. 3 .Warranty does not cover normal maintenance. 4 .Sonic Frontiers, Inc. shall not be responsible in any way for consequential or indirect damages or liabilities resulting from the use and operation of the product cov- ered herein or resulting from any breach of this warranty or any implied warranty relating to said product. During this period, Sonic Frontiers, Inc. will repair or replace any defective components free of charge. A Return Authorization (RA) Number is required before any product is returned to our factory for any reason. This number must be visible on the exterior of the shipping container(s) for Sonic Frontiers to accept the return. Units shipped to us without a Return Authorization Number or without a visible RA Number on the exterior of the shipping container(s) will be returned to the sender, freight collect. Units to be repaired by Sonic Frontiers, Inc. must be sent shipping and insurance prepaid by the original purchaser in the original packing material. A returned product should be accompanied by a written description of the defect. Repaired units will be returned by Sonic Frontiers, Inc. ship- ping and insurance prepaid. All other warranties or conditions either written or are void.SAFETY INSTRUCTIONS 1 .Water and Moisture - This product should not be used near water. Do not expose this product to rain or moisture to prevent fire or shock hazard. 2 .Heat - This product should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances which produce heat. 3 .Power Sources - This product should be connected to an AC power source of the same rated voltage. The origi- nal shipping containers will stipulate the AC voltage this unit can operate on. 4 .Cleaning - A regular dusting with a soft, non-abrasive cloth will generally keep the finish of the faceplate and chassis looking like new. At no time should you allow any liquid to come in contact with the UltrJitterbug; it may run into the electronic circuitry and cause damage which will not be covered under your warranty. 5 .Servicing - Do not open this product. No user service- able parts inside. Refer servicing to an authorized service t e c h n i c i a n . 6 .Non-Use Periods - The power cord of this product should be unplugged from the outlet when left unused for an extended period of time. DISCLAIMER OF LIABILITY Under no circumstances does Sonic Frontiers, Inc. assume liability or responsibility for injury or damages sustained in the use or operation of this equipment or for damages to any other equipment connected to it. Sonic Frontiers, Inc. reserves the right to make design changes or improvements without the obligation to revise prior versions. All specifications are subject to change without notice. Note: We recommend that you retain all of the packing materi- al and shipping boxes for your UltraJitterbug. They are custom designed to prevent shipping damage from occur- ring. Sonic Frontiers, Inc. will accept no responsibility for any damage occurring to an UltraJitterbug that is shipped in packing material other than the original Sonic Frontiers packing material.ABCDEFGHI OPERATION, CONNECTIONS AND CONTROL FUNCTIONS A-Digital Source Select Switch- This three-position toggle selects the desired input path, (Toslink - plastic fibre optical, AES/EBU - XLR connector, or RCA - coax connector). B-Source Indicator LED- One of the three LEDs will light to indicate the selected source of input. C-Locked/Unlocked LED- This LED will light when the UltraJitterbug is locked to an incoming data stream. When the LED is off the UltraJitterbug is not locked and the outputs are muted. D-IEC Socket - The detachable power cord connects here. When the UltraJitterbug is plugged in to a power source the unit is on. E-Optical - Toslink Input - This is the input socket for a S/PDIF - Toslink - plastic fiber optic connection to the digital source. F-AES/EBU Input - This is the input socket for an AES/EBU - XLR connection to the digital source. The AES/EBU cables impedance should be 110 ohms. G-Coaxial Input - This is the input socket for a coaxial - S/PDIF - RCA connection to the digital source. The coaxial - S/PDIF - RCA cables impedance should be 75 ohms. H-Coaxial Output - This is the output socket for a coaxial - S/PDIF - RCA connection to the digital-to-analog processor.The coaxial - S/PDIF - RCA cables impedance should be 75 ohms. I-AES/EBU Output - This is the output socket for an AES/EBU - XLR connection to the digital- to-analog processor. The AES/EBU cables impedance should be 110 ohms. Note:For best performance, connect only one output at a time. Any number of inputs may be connected at one time. The UltraJitterbug is factory set for the correct operating AC voltage for the area in which it is sold. If a different operating voltage is required, please contact an authorized Sonic Frontiers dealer, distributor or the factory directly.CONNECTIONS TO THE ULTRAJITTERBUG
