OPERATING MANUAL FOR THE SONIC FRONTIERS LINE SERIES PREAMPLIFIERS We at Sonic Frontiers hope you will derive many years of listening pleasure with your new LINE SeriesPreamplifier. This Operating Manual contains important information regarding the operation and care of these Preamplifiers. Be sure to read this manual carefully and fol- low these instructions in order to keep them performing and sounding their best. Please con- tact Sonic Frontiers if you have any questions - a Customer Service Representative will be pleased to assist you. C O N T E N T S Unpacking ...........................1 Operation, Connection and Control Diagrams ..........2 Control and Connection Functions ...............4 Preamplifier Set-up .....................6 Tube Insertion .......................6 Chassis Placement ......................7 Connecting External Equipment ...................7 Power Connections .........................8 Home Theatre Accessories......................8 Powering On and Startup Procedures ....................9 Remote Control Functions ..........................10 Tube Replacement .............................11 Trouble Shooting .................................11 Fuse Location ...............................11 Safety Instructions..................................12 Warranty ...................................12 Technical Specifications ...........................13 Remote Control Battery Replacement .......................14This symbol is intended to alert the user to the presence of uninsulated danger- ous voltages within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompany- ing the appliance.
Page 2
At this point we assume that you have successfully opened the box flaps and found this manual. These boxes were designed to ensure the safe transport of the LINE SeriesPreamplifiers. Sonic Frontiers strongly recommends the storage of these boxes in a safe dry place. In the event that the Line 1, Line 2, or Line 3 may have to be shipped in the future, the original boxes are the best means for the protection and safety of the preamplifier during transportation. Here is a chart listing what you will find in the box: Tube Complement - Line 1 and Line 26 - 6922 - Line 310 - 6922 2 - 6GH8A Phillips Screwdriver1 Screws18 or 36* Power Cord1 Cotton Gloves1 pair Extra Fuses2 Line 1, Line 2, or Line 3 Preamplifier1 *Line 2 or Line 3 Power Supply1 Preamplifier Top Cover1 *Power Supply Top Cover1 Remote Control1 Warranty Card1 Operating Manual1 If after your inspection of the contents there is a discrepancy, contact your dealer or Sonic Frontiers immediately. * Only for Line 2 or Line 3 owners.U N P A C K I N G
