SPECIFICATIONS Output Level (at 1000 Hz) Low lmpedance .................... Open Circuit Voltage - 78 dB* (.I25 mV) .................................... Power Level -57 dB** Type Dynamic Frequency Response 50 to 15,000 Hz (see Figure 1) FREQUENCY RESPONSE FIGURE 1 Polar Pattern Cardioid (unidirectional) pattern-Effective rejection of sound at the rear of the microphone is uniform at all frequencies, while front pickup characteristics are uniform about the axis (see Figure 2) I TYPICAL DIRECTIONAL PATTERN I FIGURE 2 Impedance DUAL. Low: Microphone rating impedance is 150 ohms (270 ohms actual) for connection to microphone inputs rated at 19 to 300 ohms. High: Microphone impedance is "High" for connection to high-impedance microphone inputs. Selection of impedance made by choice of cable leads connected at equipment end of cable (see section on lmpedance Selection). POSITIVE PRESSIRE PRDWCES POSITIVE VOLTAGE ON PIN I OR PIN 3 AWMNOL MCOF TYPE PLUG7 - - CABLE-PLUG CARTR~E GROW CASEOROUND ASSEMBLY MODEL 545 TRANSFWYER?., RED AUMNOL MCOF ! 111: TYPE cwmcTm CABLE- PLUG CARTRIDGE GROUND CASE GROUND MODEL 545s INTERNAL CONNECTIONS FIGURE 3 WELL High lmpedance .................... Open Circuit Voltage -55 dB* (1.76 mV) '0 dB = 1 volt per microbar **0 dB = 1 milliwatt per 10 microbars Switch Model 545 - None Model 5458 - Built in On-Off switch to control micro- phone circuit. The switch is an integral part of the con- nector assembly and is a slide-to-talk locking type switch Cable 4.6 meter (15 ft) three-conductor shielded with Amphenol MC4M connector on the microphone end Case Chrome-plated die casting with black ARMO-DUR8q grille and stainless steel screen Dimensions See Figure 4 Net Weight Model 545 - 255 grams (9 02.) Model 5458 - 425 grams (15 02.) L 31.8 mm 11-114 IN) MODEL 545 Z3.8 mm llS/lB IN.! MODEL 5455 OVERALL DIMENSIONS FIGURE 4 FURNISHED ACCESSORY 545 545s Swivel Adapter ................................ A25B OPTIONAL ACCESSORIES Line Matching Transformer .......... A95 Series A95 Series Vibration-Isolation Stand .............. S39A S39A Desk Stand ...................................... S33 S40A S37A, S40A Quick Disconnect Adapter ............ A45 A47 ..................................... Windscreen A2WS A2WS Carrying Case ............................... AC54 AC54S REPLACEMENT PARTS Dvnamic Cartridae .......................... R45 R45 cable and Plug assembly .............. C56 C56 .............................................. Sw~tch RK32S ................................ Case Assembly RK42C RK41 C ...................... Connector Assembly RK33CA ............................ Cable Connector RK117P RK117P ...... .................... Plug Element ... RK31 P RK31 P GUARANTEE This Shure product is guaranteed in normal use to be free from electrical and mechanical defects for a period of one year from date of purchase. Please retain proof of purchase date. This guarantee includes all parts and labor. This guar- antee is in lieu of any and all other guarantees or warranties, express or implied, and there shall be no recovery for any consequential or incidental damages. SHIPPING INSTRUCTIONS Carefully repack the unit and return it prepaid to: Shure Brothers Incorporated Attention: Service Department 1501 West Shure Drive Arlington Heights, Illinois 60004 If outside the United States, return the unit to your dealer or Authorized Shure Service Center for repair. The unit will be returned to you prepaid.
