Shure 1937 catalogue

Page 2

SHERE £27511]

NEW "ULTRA Wide-Range CRYSTAL MICROPHONES

These new Shure ULTRA" Wide-Range Crystal Microphones bring you amazingly 1i fe-like repro-
duction . . . plus new Highs in utility and dependability . . at remarkably low cost. This outstanding
performance has been attained by Shure Engineers through these exclusive advanced features :

(1) Ultra Wide-Range reproduction from 40 to "1.000 cycles. (2) Dual-Drive. High-Capacity Grafoil Crystal. (3)
Complete Barometric Compensation. (4) Internal Screen-Protected Cartridge. (5) Crystal Moisture-Sealed" by new
exclusive special process. (6) High output level through new Shure Cruciform Crystal Mounting. (7) New acous-
tically-correct single high-efficiency Curvilinear Diaphragm. (83 Beautifully styled new semi-nondirectional and semi-
directional models in Spherical. Swivel and Grille-Type" case designs.

And remember-only Shure Ultra" gives you all 8 great performance-insuring features!

WIDE-RANGE
8 Exclusive

Features!

Model 700A. A small compact unit with swivel. arrangement for use where tilting" of
microphone head is desued. Cable may be run inside or outside stand tubing. Finished
in bright polished chromium plate overall. Diameter. 23/3". Complete with 7 ft. single-

conductor shielded cable. Code: Ruret. $25
List Price ............................................................
Model 700A-25 F'l. Cable length, 25 ft. Code: Rurel. List Price ............. $26.80

Model 701A. A Grille-Type" Microphone, styled to meet the most critical taste and
designed to give outstandingly high-quality reproduction. Attractive rubber-black
screens with contrasting chromium fittings. 311,115" high. 254;," wide. 1 %" deep. Complete

with 7 ft. single-conductor shielded cable. Code: Rurev. $25
List Price ............................................................

Model 701A-25 FT. Cable length, 25 ft. Code: Rured. List Price. . . . ...... $26.80
Model 702A. A small Spherical Microphone with Semi-nondirectional pickup . . . a

feature which is especially valuable because it permits placement of a group. around
the Microphone Without frequency discrimination. Beautiful rubber-black finish With
Circular chromium band. Diameter, 2%". Complete with 7 ft. single-conductor shielded

cable. Code: Rurez. 5
List Price ............................................................ 25
Model 702A-25 FT. Cable length, 25 ft. Code: Rureg. List Price ........... $26.80

Model 70H

The Shure 70H sets the standard of performance"
for diaphragm-type crystal microphones. Adopted by
leading Sound-Equipment Manufacturers. Curvi-
linear" diaphragm and Bimorph crystal, Canti-
lever" actuated. Beautiful cast case, chromium-
plated overall. Mounts direct on any Shure Stand or
in carbon ring. Cable may be brought through stand
tubing or outside as desired. Convertible to a Hand

Model 705 "Communications-Type"

Specially designed for high-efficiency voice communica-
tion in Commercial and Amateur radiophone trans-
mitters. Highly recommended for high-intelligibility
voice-announcement P.A. systems. Doubles power on im-
portant intelligibility speech frequenCIes . . . produces
clear, crisp. powerful Signals that cut through n015e and
static. No transmitter or amplifier changes . . . connect
as you would an ordinary crystal microphone. Finished
Microphone with A40A Handle. Complete with re- in polished chromium plate and baked rubber-black en-
movable close-fitting ring, 4 Quickway Hooks amel. Complete With integral Desk Mount and 7 feet of
and shielded single-conductor rubber jacketed cable. shielded two-conductor, _rubber-Jacketed cable. Net
weight, 2 lbs. Shipping weight, 2% lbs.

Model Cable Length Code Shpg.Wt. List
70H 7 feet Rurab 1% lbs. $22.50 Model .703- Code= Rurak' $25
70H-25FT. 25 feet Rurov 2 lbs. $24.30 List Price ..............................................

. 7 S, but w'tho t Desk M t, I l .
Model 70HP. Push-Pull" Crystal Microphone. Same as 701-! except Model 7OSP Same as 0 1 u oun nc udes 7 ft

cable is two-conductor shielded. Recommended for amplifiers with
push-pull input.

Model Cable Length Code Shpg.Wt. List
70HP 7 feet Rulev l V.» lbs. $22.50
70HP-25F T. 25 feet Rulex 2 % lbs. $25.20

Model A40A (formerly 7lBH). Handle. Removable handle which fits
70H Crystal Microphone for hand use. Shipping weight. M lb.

Code: Rurij.
List Price .............................................. $15,

7OH-79AC Demountable

A complete unit consisting of the 70H Crystal Micro-
phone with plug attachment. and Stand Receptacle. In-
stantly installed! Instantly removable for safekeeping or
use elsewhere. Cable Strain Relief included. Net weight,
1 lb. Shipping weight. 1 56 lbs. No cable furnished.

Model 70H-79AC. Code: Ruram. $25 fl Vii

List Price ..................................

Model 73A Lapel Type

A light, highl efiicient lapel microphone
which faithful y reproduces the speaker's
) voice. Free from background" noise and vi-
. ..' bration pickup. Only 2" in diameter and less
I ll than 2 oz. in weight . . . small. light and in-
: : conspicuous. Also useful for general micro-
%hone applications and for hearing-aid devices. Rubber-black finish.

quipped with special spring clip and 25 ft. shielded single-conductor
black mercerized cotton-covered cable. Shipping weight. EV lb.

Model 73A. Code: Rulap. 5
List Price .............................................. 25

two-conductor shielded cable and 4 Quickway Hooks. Code: Rural.

List Price ............................................. $22.50
Model 7OSH-25FT. Same as 708? but with 25 feet of single-con-
ductor shielded cable. Code: Rump. List Price ............ $24.30

Shure Model 7'lAS Crystal
Hand Microphone

Close-Talking type. Handsome chrome-finished case
with rubber-black handle. Push-to-talk" switch in
handle. 7 ft. of special shielded. Single conductor cable.
Diameter of case 3143". Overall length 9". Shipping
weight. 1% lbs.

Model HAS. Code: Rurec. 50
List Price ............................... $26 --

Model 71A. Crystal Hand Microphone. Same as Model
71AS but without switch. Code: Rureb.
List Price .................................... $25

Model BS. Cr stal Hand Microphone. Non-Close-
talking" type. ush-to-talk" switch in handle. 7 ft. of
special cable. Code: Rurih.

List Price ................................. $25.50
Model 7113. Crystal Hand Microphone. Same as 71BS
but without sw1tch. Code: Rurig.

List Price .................................... $24

Model A8OA Stand Switch

New handy stand-mounting on-ofi switch which can be used
with any type microphone. Small attractive cast-aluminum
case, with rubber-black enamel finish. Standard %"-27 thread
fits all Shure Stands. Overall height. 2 )6". Shipping weight. 54 lb.

Model ASOA. Stand Switch. Code: Rudarn. $250
List Price ........................................ '-

SHURE BROTHERS o 225 W. HURON ST. - CHICAGO

microp/ione fleaalquarters

Cable: SHUREMICRO
