FEATURES AND SPECIFICATIONS: PT-7010A PRE/PRO/TUNER
- 24-bit, Crystal Semiconductor® analog-to-digital converter and 24-bit,
192 KHz Analog Devices® digital-to-analog converters
- 32-bit, 20 Mhz control processor
- 24-bit, 150 MIPS Motorola Sympony-„˘ DSP processor
- Dolby Digital EX, Dolby Pro Logic 2, Dolby Pro Logic 2X, DTS ES and
DTS NEO: 6 decoding modes
- Support for all digital sampling rates to 96 Khz
- Digital Domain treble and bass control as well as bass management function
- DSP simulated surround mode for enhancement of two-channel source
- Direct two-channel analog bypass mode
- Gold-plated input and output connectors and balanced XLR outputs and
unbalanced RCA outputs
- Six A/V inputs, each with audio, S-video and composite video with three A/V
outputs, each with audio, S-video and composite video
- Eight-channel analog input with separate RCA connectors for DVD-audio format
- Three component video inputs and two component video outputs
- Automatic video transcoding: up converts composite and S-video source-
to-component video
- Six coaxial and four digital inputs and coaxial and optical digital outputs,
including from analog and down mixed 5.1 sources
- AM/FM tuner with 40 presets
- Three audio only inputs including MM phono stage
- Two tape outputs
- Record outputs feature down-mixed two-channel output from a 5.1 digital source
- Four sub-woofer outputs
- 7.1 channel outputs plus stereo side outputs for a total of 9.1 channels
- Party mode for two-channel playback through all speakers
- Zone two can play sources independent of the main zone
- Trigger outputs for both zones
- IR control of both zones with rear IR ports and discrete codes
- On-screen display OSD
- RS-232 control port with discrete codes
- Flash memory upgradable through RS-232 port
- IEEE 1394 Firewire port for future expansion
- IEC standard two-prong removable power cord
SHERBOURN TECHNOLOGIES INC.
19/3A Sterling Road - North Billerica, MA 01862 USA
Tel: 978-663-7385 Fax: 978-663-7389
www. Sherbourn.com
In accordance with our policy of continual improvement, we reserve the right to change the specifications without notice.
