Page 1
XL-1000H/1100H
SHARP SERVICE MANUAL
No. S4125XL1000H/
COMPACT AUDIO SYSTEM
MODEL XL-1000H
XL-1000H Compact Audio System consisting of XL-1000H
(main unit) and CP-XL1000H (speaker system).
MODEL XL-1100H
XL-1100H Compact Audio System consisting of XL-1100H
(main unit) and CP-XL1100H (speaker system).
[flCOMPACT ' In the interests of userrsafety the set should be restored to its original
D§@ condition and only parts identical to those specified should be used.
DIGITAL AUDIO
SAVING ENERGY
SIAN BY POWER 0.6W ENE
CO SUMPTION
(For Europe)
/- CONTENTS %
SAFETY PRECAUTION FOR SERVICE MANUAL ..
IMPORTANT SERVICE NOTES (FOR UK. ONLY).
SPECIFICATIONS
ACCSSORIES ......
NAMES OF PARTS .........
OPERATION MANUAL
DISASSEMBLY ................
REMOVING AND REINSTALLING THE MAIN PARTS 1O
ADJUSTMENT... . 11
TEST MODE ...... . 12
NOTES ON SCHEMATIC DIAGRAM .. 19
TYPES OF TRANSISTOR AND LED .. 19
WAVEFORMS OF CD CIRCUIT .. 2O
BLOCK DIAGRAM ........... .. 21
SCHEMATIC DIAGRAM ..
WIRING SIDE OF P.W.BOARD.
TROUBLESHOOTING .....
FUNCTION TABLE OF lC
LCD SEGMENT ..................
PARTS GUIDE/EXPLODED VIEW
PACKING METHOD (FOR UK. ONLY)
This document has been published to be used
SHARP CORPORATION for alter sales service only.
The contents are subject to change without notice.
