Sharp rt 3838h
This is the 43 pages manual for sharp rt 3838h.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sharp rt 3838h (Ocr-read)
Page 1
= OPTONICA
SERVICE MANUAL
R T8838 H
DE] DOLBY SYSTEM ®
4 "Dolby" and the "Double
* Manufactured under licence from Dolby Laboratories.
ELECTRONIC TAPE
PROCESSOR
MODEL
RT-3838H
[ln the interests OI user-safety the set should be restored to its original condition and only parts identical to
those specified be used."
SPECIFICATIONS
Type: 4-track 2-channel stereo Cassette tape
recorder/ player deck with builtin
Dolby noise reduction system
Power source: AC llO/220/240V, 50/60 Hz
Power consumption: 18 Watts
Semiconductors: l-LSI (Large Scale Integrated Circuit)
7~lC (integrated Circuit)
59-Transistor
34Diode
Z-LED (Light Emitting Diode)
Dimensions:
Width. 442 mm (173/8")
Height: 144 mm (Bell/16")
Depth: 357 mm (14-1/16)
Weight: 9 kg (199 lbs)
Tape: Philips standard compact cassette tape
Wow & flutter:
Frequency response
Use of normal tape:
30 ~ 13,000 Hz
under D|N45 500
Use of FeCr tape:
30 ~ 16,000 Hz
under D|N45 500
0,15% (DIN45 500)
Use of MAXELL UDXLII tape:
30 ~ 15,000 Hz
under DIN45 500
Better than 50 dB, for normal tape
(weighted) at LlNE~IN, without Dolby
Noise Reduction.
Dolby NR effect: 10 dB lat over Ski-l2)
Input sensitivity and input impedance:
S/N ratio
Microphone: 0.2 mV
l6.8l< ohms)
Line 50 mV (54k ohms)
Record/playback socket
O.lmV/l< ohm
Output level and loaded impedance:
Headphones: 89 mV
(0' VU), 8ohm
Line: 775 mV ('OVU)
50k ohms
Record/playback socket.
775 mV (0 V0)
