RP-111H(S
SHARP
SERVICE MANUAL/ SERVICE-MLEITUNG/ MANUEL DE SERVICE
PHOTO: RP-111HIS)
®
((9---INDEX TO CONTENTS-fl
Page Page
SPECIFICATIONS ........................ 2, 3 SCHEMATIC DIAGRAM .................... 9,10
NAMES OF PARTS ........................ 2, 3 WIRING SIDE OF P.W. BOARD ................ 11
DISASSEMBLY .......................... 4, 5 NOTES ON SCHEMATIC DIAGRAM ............. 12
BLOCK DIAGRAM .......................... 6 EXPLODED VIEW ......................... 13
SETTING OF PLAYER WIRE ................... 6 PACKING METHOD (FOR UK) ................ 14
CIRCUIT ADJUSTMENT .................... 7, 8 REPLACEMENT PARTS LIST ............. 15 - 18
MECHANICAL ADJUSTMENT ................ 7, B
INHALTZVERZEICHNIS
® Seite Seite
TECHNISCHE DATEN ..................... 2, 3 MECHANISCHE EINSTELLUNG .............. 7, 8
TEILEBEZEICHNUNG ..................... 2, 3 SCHEMATISCHER SCHALTPLAN ............ 9,10
ZERLEGEN ............................. 4, 5 VERDRAHTUNGSSEITE DER LEITERPLATTE ..... 11
BLOCKSCHALTPLAN ........................ 6 HINWEISE ZUM SCHEMATISCHEN SCHALTPLAN . .12
EINSETZEN DES PLATTENSPIELER EXPLOSIONSDARSTELLUNG ................ 13
ANTRIEBSDRAHTS ....................... 6 ERSATZTEILLISTE .................... 15 - 18
SCHALTUNGSEINSTELLUNG ................ 7, 8
TABLE DES MATIEREs
$6447RP-111HS
RP-111H(S)(BK)(BR)(W)
RP-111E(S)
I In the interests of user-safety the set should be restored to its
original condition and only parts identical to those specified be
used.
0 Im Interesse der Benutzer-Sicherheit sollte dieses Gerét wieder auf
seinen urspriinglichen Zustand eingestellt und nur die vorgeschrie-
benen Teile verwendet warden.
IDans l'intérét de la sécurité cle l'utilisateur, l'appareil devra étre
reconstitute dens sa condition premiére et seules des pieces iden-
tiques é celles spécifiees, doivent étre utilisées.
Page Page
CARACTERISTIOUES ..................... 2, 3 DIAGRAMME SCHEMATIOUE .............. 9,10
NOMENCLATURE ........................ 2, 3 COTE CABLAGE DE LA PLAQUETTE DE MONTAGE
DEMONTAGE ........................... 4,5 IMPRIME . .~ ............................ 11
DIAGRAMME SYNOPTIQUE ................... e REMAROUES CONCERNANT LE DIAGRAMME
REGLAGE DU FIL DU TOURNEDISQUES ......... 6 SCHEMATIOUE ......................... 12
REGLAGE DU CIRCUIT .................... 7,8 VUE EN ECLATE ......................... 13
REGLAGE MECHANIQUE .................. 7, 8 LISTE DES PIECES DE RECHANGE ........ 15 - 18
K J
SHARP CORPORATION
Page 1
RP-111H(S
SHARP
SERVICE MANUAL/ SERVICE-MLEITUNG/ MANUEL DE SERVICE
PHOTO: RP-111HIS)
®
((9---INDEX TO CONTENTS-fl
Page Page
SPECIFICATIONS ........................ 2, 3 SCHEMATIC DIAGRAM .................... 9,10
NAMES OF PARTS ........................ 2, 3 WIRING SIDE OF P.W. BOARD ................ 11
DISASSEMBLY .......................... 4, 5 NOTES ON SCHEMATIC DIAGRAM ............. 12
BLOCK DIAGRAM .......................... 6 EXPLODED VIEW ......................... 13
SETTING OF PLAYER WIRE ................... 6 PACKING METHOD (FOR UK) ................ 14
CIRCUIT ADJUSTMENT .................... 7, 8 REPLACEMENT PARTS LIST ............. 15 - 18
MECHANICAL ADJUSTMENT ................ 7, B
INHALTZVERZEICHNIS
® Seite Seite
TECHNISCHE DATEN ..................... 2, 3 MECHANISCHE EINSTELLUNG .............. 7, 8
TEILEBEZEICHNUNG ..................... 2, 3 SCHEMATISCHER SCHALTPLAN ............ 9,10
ZERLEGEN ............................. 4, 5 VERDRAHTUNGSSEITE DER LEITERPLATTE ..... 11
BLOCKSCHALTPLAN ........................ 6 HINWEISE ZUM SCHEMATISCHEN SCHALTPLAN . .12
EINSETZEN DES PLATTENSPIELER EXPLOSIONSDARSTELLUNG ................ 13
ANTRIEBSDRAHTS ....................... 6 ERSATZTEILLISTE .................... 15 - 18
SCHALTUNGSEINSTELLUNG ................ 7, 8
TABLE DES MATIEREs
$6447RP-111HS
RP-111H(S)(BK)(BR)(W)
RP-111E(S)
I In the interests of user-safety the set should be restored to its
original condition and only parts identical to those specified be
used.
0 Im Interesse der Benutzer-Sicherheit sollte dieses Gerét wieder auf
seinen urspriinglichen Zustand eingestellt und nur die vorgeschrie-
benen Teile verwendet warden.
IDans l'intérét de la sécurité cle l'utilisateur, l'appareil devra étre
reconstitute dens sa condition premiére et seules des pieces iden-
tiques é celles spécifiees, doivent étre utilisées.
Page Page
CARACTERISTIOUES ..................... 2, 3 DIAGRAMME SCHEMATIOUE .............. 9,10
NOMENCLATURE ........................ 2, 3 COTE CABLAGE DE LA PLAQUETTE DE MONTAGE
DEMONTAGE ........................... 4,5 IMPRIME . .~ ............................ 11
DIAGRAMME SYNOPTIQUE ................... e REMAROUES CONCERNANT LE DIAGRAMME
REGLAGE DU FIL DU TOURNEDISQUES ......... 6 SCHEMATIOUE ......................... 12
REGLAGE DU CIRCUIT .................... 7,8 VUE EN ECLATE ......................... 13
REGLAGE MECHANIQUE .................. 7, 8 LISTE DES PIECES DE RECHANGE ........ 15 - 18
K J
SHARP CORPORATION
Page 2
GENERAL
Dimensions: Width; 330 mm (13)
Height; 108 mm (4"),(including dust
cover)
Depth; 350mm (13-3/4"!
Weight; .3 _|
Type: Linear tracking fully automatic
Motor: DC motor (for platter drive) x 1
DC motor (for tonearm drive) x 1
Belt drive
33-1/3 rpm and 45 rpm
i0.09% (DIN 45 507)
0.07% (WRMS)
Drive system:
Speeds:
Wow and flutter:
Rumble:
SPECIFICATIONS '-.:-
TON EARM
Type:
Dynamic balanced linear tracking arm
Effective length:
147 mm (5-3/4")
Tracking error angle: i0.2°
CARTRIDGE
Type: Magnetic type
Frequency response: '20 Hz - 20,000 Hz
Output:
Channel separation:
Tracking force:
Impedance:
Compliance:
Replacement stylus:
mV (1 kHz
50 mm/sec.)
Specifications for this model are subject to change without
prior notice.
NAM ES 0F PARTS
60 dB (DIN B)
Turntable: 28cm (11). '
1. 17 cm (7") EP Record Adaptor
2. Turntable Platter and Mat
3. Center Spindle
4. Dust Cover
5. Tonearm
6. Tonearm Rest
7. Cartridge
8. Power Switch
9. Record Size Selector Button
10. Speed Selector (33/45) Button
11. Power Indicator
12. Tonearm Forward Button
13. Tonearm Reverse Button
14. Cue Button
15. Play/Cut Button
16. Input/Output Plug
1 4
5
2 $
3 ll
E5 :3: Lg...
8 910 11 12131415
Figure 2-1
16
Figure 2-2
