Page 1
M D-X60
SHARP SERVICE MANUAL
No.56839MDX60/H
MD-X60
on-
. Dolby noise reduction manutactured under license from Dolby
Laboratories Licensing Corporation.
0 "DOLBY" and the double-D symbol DE] are trademarks of Dolby
Laboramnes Licensmg Corporation. . In the interests of userrsatety the set should be restored to its original
. It is the intent of Sharp that this product be used in full compliance condition and only parts identical to those specified should be used.
with the copyright laws of the United States and that prior permission
be obtined from copyright owners whenever necessary.
0 US and toreign patents licensed from Dolby Laboratories Licensing
Corporation.
I lfiOMPACT
DIGITAL AUDIO
/- CONTENTS -\
IMPOTANT SERVICE NOTES
SPECIFICATIONS ..
NAMES OF PARTS
OPERATION MANUAL ..
QUICK GUIDE ..
DISASSEMBLY.
REMOVING AND REINSTALLING THE MAIN PARTS
ADJUSTMENT ........
WIRING DIAGRAM.
BLOCK DIAGRAM ..
SCHEMATIC DIAGR
NOTES ON SCHEMATIC DIAGRAM
TYPE OF TRANSISTOR AND LED
WAVEFORMS OF CD CIRCUIT.
WAVEFORMS OF MD CIRCUIT
TROUBLESHOOTING (CD SECTIO )
TROUBLESHOOTING (MD SECTION)
FUNCTION TABLE OF IC .....................
REPLACEMENT PARTS LlST/EXPLODED VIEW/PACKING OF THE SET
This document has been published to be used
SHARP CORPORATION for after sales service only.
The contents are subject to change without notice.
Page 1
M D-X60
SHARP SERVICE MANUAL
No.56839MDX60/H
MD-X60
on-
. Dolby noise reduction manutactured under license from Dolby
Laboratories Licensing Corporation.
0 "DOLBY" and the double-D symbol DE] are trademarks of Dolby
Laboramnes Licensmg Corporation. . In the interests of userrsatety the set should be restored to its original
. It is the intent of Sharp that this product be used in full compliance condition and only parts identical to those specified should be used.
with the copyright laws of the United States and that prior permission
be obtined from copyright owners whenever necessary.
0 US and toreign patents licensed from Dolby Laboratories Licensing
Corporation.
I lfiOMPACT
DIGITAL AUDIO
/- CONTENTS -\
IMPOTANT SERVICE NOTES
SPECIFICATIONS ..
NAMES OF PARTS
OPERATION MANUAL ..
QUICK GUIDE ..
DISASSEMBLY.
REMOVING AND REINSTALLING THE MAIN PARTS
ADJUSTMENT ........
WIRING DIAGRAM.
BLOCK DIAGRAM ..
SCHEMATIC DIAGR
NOTES ON SCHEMATIC DIAGRAM
TYPE OF TRANSISTOR AND LED
WAVEFORMS OF CD CIRCUIT.
WAVEFORMS OF MD CIRCUIT
TROUBLESHOOTING (CD SECTIO )
TROUBLESHOOTING (MD SECTION)
FUNCTION TABLE OF IC .....................
REPLACEMENT PARTS LlST/EXPLODED VIEW/PACKING OF THE SET
This document has been published to be used
SHARP CORPORATION for after sales service only.
The contents are subject to change without notice.
Page 1
M D-X60
SHARP SERVICE MANUAL
No.56839MDX60/H
MD-X60
on-
. Dolby noise reduction manutactured under license from Dolby
Laboratories Licensing Corporation.
0 "DOLBY" and the double-D symbol DE] are trademarks of Dolby
Laboramnes Licensmg Corporation. . In the interests of userrsatety the set should be restored to its original
. It is the intent of Sharp that this product be used in full compliance condition and only parts identical to those specified should be used.
with the copyright laws of the United States and that prior permission
be obtined from copyright owners whenever necessary.
0 US and toreign patents licensed from Dolby Laboratories Licensing
Corporation.
I lfiOMPACT
DIGITAL AUDIO
/- CONTENTS -\
IMPOTANT SERVICE NOTES
SPECIFICATIONS ..
NAMES OF PARTS
OPERATION MANUAL ..
QUICK GUIDE ..
DISASSEMBLY.
REMOVING AND REINSTALLING THE MAIN PARTS
ADJUSTMENT ........
WIRING DIAGRAM.
BLOCK DIAGRAM ..
SCHEMATIC DIAGR
NOTES ON SCHEMATIC DIAGRAM
TYPE OF TRANSISTOR AND LED
WAVEFORMS OF CD CIRCUIT.
WAVEFORMS OF MD CIRCUIT
TROUBLESHOOTING (CD SECTIO )
TROUBLESHOOTING (MD SECTION)
FUNCTION TABLE OF IC .....................
REPLACEMENT PARTS LlST/EXPLODED VIEW/PACKING OF THE SET
This document has been published to be used
SHARP CORPORATION for after sales service only.
The contents are subject to change without notice.
Page 1
M D-X60
SHARP SERVICE MANUAL
No.56839MDX60/H
MD-X60
on-
. Dolby noise reduction manutactured under license from Dolby
Laboratories Licensing Corporation.
0 "DOLBY" and the double-D symbol DE] are trademarks of Dolby
Laboramnes Licensmg Corporation. . In the interests of userrsatety the set should be restored to its original
. It is the intent of Sharp that this product be used in full compliance condition and only parts identical to those specified should be used.
with the copyright laws of the United States and that prior permission
be obtined from copyright owners whenever necessary.
0 US and toreign patents licensed from Dolby Laboratories Licensing
Corporation.
I lfiOMPACT
DIGITAL AUDIO
/- CONTENTS -\
IMPOTANT SERVICE NOTES
SPECIFICATIONS ..
NAMES OF PARTS
OPERATION MANUAL ..
QUICK GUIDE ..
DISASSEMBLY.
REMOVING AND REINSTALLING THE MAIN PARTS
ADJUSTMENT ........
WIRING DIAGRAM.
BLOCK DIAGRAM ..
SCHEMATIC DIAGR
NOTES ON SCHEMATIC DIAGRAM
TYPE OF TRANSISTOR AND LED
WAVEFORMS OF CD CIRCUIT.
WAVEFORMS OF MD CIRCUIT
TROUBLESHOOTING (CD SECTIO )
TROUBLESHOOTING (MD SECTION)
FUNCTION TABLE OF IC .....................
REPLACEMENT PARTS LlST/EXPLODED VIEW/PACKING OF THE SET
This document has been published to be used
SHARP CORPORATION for after sales service only.
The contents are subject to change without notice.
Page 2
MD-X60
TO THE OPERATION MANUAL.
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
IMPORTANT SERVICE NOTES
BEFORE RETURNING THE AUDIO PRODUCT
(Fire & Shock Hazard)
Before returning the audio product to the user, perform the following
safety checks.
1. Inspect all lead dress to make certain that leads are not pinched
or that hardware is not lodged between the chassis and other
metal parts in the audio product.
2. Inspect all protective devices such as insulating materials, cabinet,
terminal board, adjustment and compartment covers or shields,
mechanical insulators etc.
3. To be sure that no shock hazard exists, check for leakage current
in the following manner.
Plug the AC line cord directly into a 120 volt AC outlet.
Using two clip leads, connect a 1 .5k ohm, 10 watt resistor paralleled
by a 0.15pF capacitor in series with all exposed metal cabinet
parts and a known earth ground, such as conduit or electrical
ground connected to earth ground.
Use a VTVM or VOM with 1000 ohm per volt, or higher, sensitivity
to measurethe AC voltage drop across the resistor (See diagram).
Connect the resistor connection to all exposed metal parts having
a return path to the chassis (antenna, metal cabinet, screw heads,
knobs and control shafts, escutcheon, etc.) and measure the AC
voltage drop across the resistor.
4%
VTVM
-0AC SCALEO-
1.5k ohms
10W
0.15pF
TEST PROBE CONNECT TO
KNOWN EARTH
GROUND
All check must be repeated with the AC line cord plug connection
reversed.
Any reading of 0.3 volt RMS (this corresponds to 0.2 milliamp. AC.)
or more is excessive and indicates a potential shock hazard which
must be corrected before returning the audio product to the owner.
TO EXPOSED
METAL PARTS
SPECIFICATIONS
