Page 2
S ECIAL NOTES
The mains lead of this product is fitted with a non-rewireable
(moulded) plug incorporating a 3A fuse. Should the fuse need
to be replaced, a BSI or ASTA approved BS 1362 fuse marked
® or® and ofthe same rating as above, which is also indicated
on the pin face of the plug must be used.
Always refit the fuse cover after replacing the fuse. Never use
the plug without the fuse cover fitted.
In the unlikely event of the socket outlet in your home not being
compatible with the plug supplied, cut-off the mains plug and fit
an appropriate type.
DANGER:
The fuse from the cut-off plug should be removed and the cut-
off plug destroyed immediately and disposed of in a safe
manner.
Under no circumstances should the cut-off plug be inserted
elsewhere into a 13A socket outlet as a serious electric shock
may occur.
To fit an appropriate plug to the mains lead, follow the instruc-
tions below:
IMPORTANT:
The wires in the mains lead are coloured in accordance with the
following code:
Blue
Brown
: Neutral
: Live
As the colours of the wires in the mains lead of this product may
not correspond With the coloured markings identifying the
terminals in your plug, proceed as follows:
0 The wire which is coloured blue must be connected tothe plug
terminal which is marked N or coloured black.
0 The wire which is coloured brown must be connected to the
plug terminal which is marked L or coloured red.
NOTE FOR USERS IN THE UK.
Ensure that neither the brown nor the blue wire is connected to
the earth terminal in your three pin plug.
Before replacing the plug cover, make sure that:
o If the new fitted plug contains a fuse, its value is the same as
that removed from the cut-off plug.
0 The cord grip is clamped overthe sheath ofthe mains lead and
not simply over the lead wires.
IF YOU HAVE ANY DOUBT, CONSULT A QUALIFIED ELEC-
TRICIAN.
SERVICE INFORMATION
In the unlikely event of your equipment requiring repair, please
contact the dealer or supplier from whom it was purchased.
Where this is not possible, please contact the telephone number
listed below, You will then be given details of how to obtain
service.
0345425387
Please note; all calls will be charged at local rate.
Certain replacement parts and accessories may be obtained
from our main parts distributor, who can be contacted on the
following numbers;
WILLOW VALE ELECTRONICS LTD.
MANCHESTER
READING
O1 61 -682-1415
01734-876444
In the unlikely event of this equipment requiring repair during
the guarantee period, you will need to provide proof of the date
of purchase to the repairing company.
Please keep your invoice or receipt, which is supplied at the
time of purchase.
0 Recording and playback of any material may require consent,
which SHARP is unable to give. Please refer particularly to the
provisions of the Copyright Act 1956, the Dramatic and Musical
Performers Protection Act 1958, the Performers Protection
Acts 1963 and 1972 and to any subsequentstatutory enactments
and orders.
0 This equipment complies with the requirements of Directives 89/
SSS/EEC and 73/23/EEC as amended by 93/68/EEC.
. SRS technology Licensed from SRS Labs. SRS technology
holds the following patents:U.S. Patent No. 4,748,669 and U.S.
Patent No. 4,841,572.
0 SRS, the SRS LogoCO) and the scum: RETRIEVAL SYSTEMare
registered trademarks of SR8 Labs, Inc. in the United States.
on-
o Dolby noise reduction manufactured under license from Dolby
Laboratories Licensing Corporation.
0 DOLBY and the double-D symbol UK] are trademarks of Dolby
Laboratories Licensing Corporation.
Us and foreign patents licensed from Dolby Laboratories
Licensing Corporation.
0 When the POWER switch is set at STAND-BY position mains
voltage is still present inside the unit.
When the POWER switch is set at STAND-BY position and the
clock is displayed, the unit may be brought into operation by use
of (timer mode or) remote control.
Warning:
This unit contains no user serviceable parts. Never remove
covers unless qualified to do so. This unit contains dangerous
voltages, always remove mains plug from the socket before any
service operation and when not in use for a long period.
%
@ E]
lfi
cuss 1 LASEII PRODUCT
APPAREIL A LASER DE CLASSE I S
PRODUETG LASER DE CLASE i :l Em;
At
Caution:
Use the MD/CD component system only in accordance with the
instructions given in this manual and do not attempt to interfere with
the interlock switch or make any other adjustment as this may result
in exposure to hazardous radiation.
