Sharp md r 3 owners manual
This is the 48 pages manual for sharp md r 3 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sharp md r 3 owners manual (Ocr-read)
Page 1
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE ANTENNA LEAD IN WIRE ANTENNA DISCHARGE UNIT (NEC SECTION 810-20) GROUNDING CONDUCTORS (NEC SECTION 810-21) GROUND CLAMPS POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H) NEC - NATIONAL ELECTRICAL CODE S2898AELECTRIC SERVICE EQUIPMENTGROUND CLAMP IMPORTANT SAFEGUARDS CAUTION All the safety and operating instructions should be read be- fore the appliance is operated, and should be retained for future reference. Electrical energy can perform many useful functions. This unit has been engineered and manufactured to assure your personal safety. Improper use can result in potential electrical shock or fire hazards. In order not to defeat the safeguards, observe the following basic rules for its installation, use and servicing. MD-R3 ACCESSORIES Remote control x 1 (RRMCG0142AWSA) Note: Parts and accessories mentioned in this opera- tion manual other than those shown to the left are not included. Analog connecting cable x 2 (QCNWG0003AWZZ) ©AAª size battery (UM/SUM-3, R6, HP-7 or similar) x 2 (for remote control) (UBATU0001AWZZ) 1 Heed Warnings - All warnings on the appliance and in the oper- ating instructions should be adhered to. 2 Follow Instructions - All operating and use instructions should be followed. 3 Water and Moisture - The appliance should not be used near water - for example, near a bathtub, washbowl, kitchen sink, laun- dry tub, in a wet basement, or near a swimming pool, etc. 4 Carts and Stands - The appliance should be used only with a cart or stand that is recommended by the manufacturer. · An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven sur- faces may cause the appliance and cart com- bination to overturn. 5 Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer. 6 Ventilation - The appliance should be situated so that its location or position does not interfere with its proper ventilation. For ex- ample, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings; or, placed in a built-in installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings. 7 Heat - The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (in- cluding amplifiers) that produce heat. 8 Power Sources - The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance. 9 Power-Cord Protection - Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance. 10 Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 11 Power Lines - An outdoor antenna should be located away from power lines. 12 Outdoor Antenna Grounding - If an outside antenna is connected to the receiver, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna-discharge unit, size of grounding con- ductors, location of antenna-discharge unit, connection to ground- ing electrodes, and requirements for the grounding electrode. 13 Nonuse Periods - The power cord of the appliance should be unplugged from the outlet when left unused for a long period of time. 14 Object and Liquid Entry - Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through openings. 15 Damage Requiring Service - The appliance should be serviced by qualified service personnel when: A The power-supply cord or the plug has been damaged; or B Objects have fallen, or liquid has been spilled into the appliance; or C The appliance has been exposed to rain; or D The appliance does not appear to operate normally or exhibits a marked change in performance; or E The appliance has been dropped, or the enclosure damaged. 16 Servicing - The user should not attempt to service the appliance beyond that described in the operating instructions. All other ser- vicing should be referred to qualified service personnel. 17 Grounding or Polarization - Precautions should be taken so that the grounding or polarization means of an appliance is not de- feated. CONTENTS Page ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 NAMES OF CONTROLS AND INDICATORS . . . . . . . . 3 REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 7 SETTING THE CLOCK . . . . . . . . . . . . . . . . . . . . . . . 8 - 9 MINIDISC OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . 10 COMPACT DISC OPERATION . . . . . . . . . . . . . . . 11 - 12 CD AND MD OPERATIONS . . . . . . . . . . . . . . . . . 13 - 17 RECORDING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 - 24Page EDITING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 - 35 HOW TO USE THE BUILT-IN TIMER . . . . . . . . 36 - 38 WHAT IS A MINIDISC? . . . . . . . . . . . . . . . . . . . 39 - 40 MINIDISC SYSTEM LIMITATIONS . . . . . . . . . . . . . . . . 40 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . 41 - 43 TRANSPORTING THE UNIT . . . . . . . . . . . . . . . . . . . . . 43 MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 LIMITED WARRANTY . . . . . . . . . . . . . . . . . . Back cover 1
Page 2
PRECAUTIONS nGeneral lDo not use oil, solvents, gasoline, paint thinners or insecticides on the unit. lDo not expose the unit to moisture, to temperatures higher than 140 oF (60 oC) or to extreme low temperatures. lKeep the unit away from direct sunlight, strong magnetic fields, excessive dust, humidity and electronic/electrical equipment (home computers, facsimiles, etc.) which generates electrical noise. lHold the AC power plug by the head when removing it from the AC outlet, since pulling the cord can damage internal wires. lNever open the cabinet. If a foreign object drops into the set, contact your dealer. lUse the unit on a firm, level surface free from vibration, and do not place anything on the top of the unit. lIf the unit malfunctions while in use, press the POWER button to turn the power off, then disconnect the AC power cord from the AC outlet. Plug the AC power cord back in, and then press the POWER button to turn the power on. lIf a lightning storm is taking place near you, it is suggested that you disconnect the AC power cord from the AC outlet for safety. lBefore moving the unit, be sure to remove all CDs and MDs from the unit. Then, turn the power off and unplug the AC power cord. If you move the unit with CDs or MDs left in it, they may jam inside the unit, leading to damage. Warning:The voltage used must be the same as that specified on this unit. Using this product with a higher voltage than that which is specified is dangerous and may result in a fire or other type of accident causing damage. SHARP will not be held responsible for any damage resulting from use of this unit with a voltage other than that which is specified. nInstallation location Do not install the unit in the following places. Otherwise, it may cause unit malfunctions or accidents. lPlaces exposed to vibration. lPlaces exposed to direct sunlight for many hours. lPlaces where temperatures are excessively high or low. lPlaces exposed to high humidity. lPlaces exposed to excessive dust. lPoorly ventilated places. lPlaces exposed to water, for example, a bathroom. lPlaces near objects which generate magnetism or electric noise. nCondensation Sudden temperature changes, storage or operation in an ex- tremely humid environment may cause condensation inside the cabinet (CD pickup, MD pickup, etc.) or on the transmitter window on the remote control. Condensation can cause the unit to malfunction. If this happens, leave the power on with no disc in the unit until normal playback is possible (about 1 hour) or wipe off any condensation on the transmitter window with a soft cloth before operating the unit. nCare of compact discs Compact discs are fairly resistant to damage, however mistracking can occur due to an accumulation of dirt on the disc surface. Follow the guidelines below for maximum enjoyment from your CD collection and player. lDo not write on either side of the disc, particularly the non-label side. Signals are read from the non-label side. Do not mark this surface. lKeep your discs away from direct sunlight, heat, and excessive moisture. lAlways hold the CDs by the edges. Fingerprints, dirt, or water on the CDs can cause noise or mistracking. If a CD is dirty or does not play properly, clean it with a soft, dry cloth, wiping straight out from the center, along the radius. No Yes MD-R3 2
