sharp md r 2 owners manual

Extracted text from sharp md r 2 owners manual (Ocr-read)

Page 1

EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE ANTENNA LEAD IN WIRE ANTENNA DISCHARGE UNIT (NEC SECTION 810-20) GROUNDING CONDUCTORS (NEC SECTION 810-21) GROUND CLAMPS POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H) NEC - NATIONAL ELECTRICAL CODE S2898AELECTRIC SERVICE EQUIPMENTGROUND CLAMP IMPORTANT SAFEGUARDS CAUTION All the safety and operating instructions should be read before the appliance is operated, and should be retained for future reference. Electrical energy can perform many useful functions. This unit has been engineered and manufactured to assure your personal safety. Improper use can result in potential electrical shock or fire hazards. In order not to defeat the safeguards, observe the following basic rules for its installation, use and servicing. MD-R2 ACCESSORIES Remote control x 1 (RRMCG0123AWSA) Note: Parts and accessories mentioned in this opera- tion manual other than those shown to the left are not included. Analog connecting cable x 2 (QCNWG0003AWZZ) ©AAª size battery (UM/SUM-3, R6, HP-7 or similar) x 2 (for remote control) (UBATU0001AWZZ) 1 Heed Warnings - All warnings on the appliance and in the operat- ing instructions should be adhered to. 2 Follow Instructions - All operating and use instructions should be followed. 3 Water and Moisture - The appliance should not be used near water - for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc. 4 Carts and Stands - The appliance should be used only with a cart or stand that is recommended by the manufacturer. · An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven sur- faces may cause the appliance and cart com- bination to overturn. 5 Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer. 6 Ventilation - The appliance should be situated so that its location or position does not interfere with its proper ventilation. For ex- ample, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings; or, placed in a built-in installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings. 7 Heat - The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (in- cluding amplifiers) that produce heat. 8 Power Sources - The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance. 9 Power-Cord Protection - Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance. 10 Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 11 Power Lines - An outdoor antenna should be located away from power lines. 12 Outdoor Antenna Grounding - If an outside antenna is connected to the receiver, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna-discharge unit, size of grounding con- ductors, location of antenna-discharge unit, connection to ground- ing electrodes, and requirements for the grounding electrode. 13 Nonuse Periods - The power cord of the appliance should be unplugged from the outlet when left unused for a long period of time. 14 Object and Liquid Entry - Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through openings. 15 Damage Requiring Service - The appliance should be serviced by qualified service personnel when: A The power-supply cord or the plug has been damaged; or B Objects have fallen, or liquid has been spilled into the appliance; or C The appliance has been exposed to rain; or D The appliance does not appear to operate normally or exhibits a marked change in performance; or E The appliance has been dropped, or the enclosure damaged. 16 Servicing - The user should not attempt to service the appliance beyond that described in the operating instructions. All other ser- vicing should be referred to qualified service personnel. 17 Grounding or Polarization - Precautions should be taken so that the grounding or polarization means of an appliance is not defeated. CONTENTS Page ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 NAMES OF CONTROLS AND INDICATORS . . . . . . . . 3 REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 7 SETTING THE CLOCK . . . . . . . . . . . . . . . . . . . . . . . 8 - 9 PLAYING A MINIDISC . . . . . . . . . . . . . . . . . . . . . 10 - 14 RECORDING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 - 19Page EDITING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 - 30 HOW TO USE THE BUILT-IN TIMER . . . . . . . . 31 - 33 MINIDISC SYSTEM LIMITATIONS . . . . . . . . . . . . . . . . 33 WHAT IS A MINIDISC? . . . . . . . . . . . . . . . . . . . 34 - 35 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . 35 - 37 MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 LIMITED WARRANTY . . . . . . . . . . . . . . . . . . Back cover 1

Page 1

EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE ANTENNA LEAD IN WIRE ANTENNA DISCHARGE UNIT (NEC SECTION 810-20) GROUNDING CONDUCTORS (NEC SECTION 810-21) GROUND CLAMPS POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H) NEC - NATIONAL ELECTRICAL CODE S2898AELECTRIC SERVICE EQUIPMENTGROUND CLAMP IMPORTANT SAFEGUARDS CAUTION All the safety and operating instructions should be read before the appliance is operated, and should be retained for future reference. Electrical energy can perform many useful functions. This unit has been engineered and manufactured to assure your personal safety. Improper use can result in potential electrical shock or fire hazards. In order not to defeat the safeguards, observe the following basic rules for its installation, use and servicing. MD-R2 ACCESSORIES Remote control x 1 (RRMCG0123AWSA) Note: Parts and accessories mentioned in this opera- tion manual other than those shown to the left are not included. Analog connecting cable x 2 (QCNWG0003AWZZ) ©AAª size battery (UM/SUM-3, R6, HP-7 or similar) x 2 (for remote control) (UBATU0001AWZZ) 1 Heed Warnings - All warnings on the appliance and in the operat- ing instructions should be adhered to. 2 Follow Instructions - All operating and use instructions should be followed. 3 Water and Moisture - The appliance should not be used near water - for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc. 4 Carts and Stands - The appliance should be used only with a cart or stand that is recommended by the manufacturer. · An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven sur- faces may cause the appliance and cart com- bination to overturn. 5 Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer. 6 Ventilation - The appliance should be situated so that its location or position does not interfere with its proper ventilation. For ex- ample, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings; or, placed in a built-in installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings. 7 Heat - The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (in- cluding amplifiers) that produce heat. 8 Power Sources - The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance. 9 Power-Cord Protection - Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance. 10 Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 11 Power Lines - An outdoor antenna should be located away from power lines. 12 Outdoor Antenna Grounding - If an outside antenna is connected to the receiver, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna-discharge unit, size of grounding con- ductors, location of antenna-discharge unit, connection to ground- ing electrodes, and requirements for the grounding electrode. 13 Nonuse Periods - The power cord of the appliance should be unplugged from the outlet when left unused for a long period of time. 14 Object and Liquid Entry - Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through openings. 15 Damage Requiring Service - The appliance should be serviced by qualified service personnel when: A The power-supply cord or the plug has been damaged; or B Objects have fallen, or liquid has been spilled into the appliance; or C The appliance has been exposed to rain; or D The appliance does not appear to operate normally or exhibits a marked change in performance; or E The appliance has been dropped, or the enclosure damaged. 16 Servicing - The user should not attempt to service the appliance beyond that described in the operating instructions. All other ser- vicing should be referred to qualified service personnel. 17 Grounding or Polarization - Precautions should be taken so that the grounding or polarization means of an appliance is not defeated. CONTENTS Page ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 NAMES OF CONTROLS AND INDICATORS . . . . . . . . 3 REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 7 SETTING THE CLOCK . . . . . . . . . . . . . . . . . . . . . . . 8 - 9 PLAYING A MINIDISC . . . . . . . . . . . . . . . . . . . . . 10 - 14 RECORDING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 - 19Page EDITING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 - 30 HOW TO USE THE BUILT-IN TIMER . . . . . . . . 31 - 33 MINIDISC SYSTEM LIMITATIONS . . . . . . . . . . . . . . . . 33 WHAT IS A MINIDISC? . . . . . . . . . . . . . . . . . . . 34 - 35 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . 35 - 37 MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 LIMITED WARRANTY . . . . . . . . . . . . . . . . . . Back cover 1

Page 2

FEATURES DAT tapes can be digitally recorded directly onto a MiniDisc. The MiniDisc unit has a built-in sampling rate convertor which allows the unit to be connected to various types of digital equipment. You can record from a large variety of digital formats. Supports various types of digital/analog equipmentTwo digital input jacks and two analog input jacks are built in. They allow the unit to be connected to stereos or head- phone stereos. Recordings start automatically when the external sound source starts to produce sound. Comes with a sound synchro recording function, which allows the unit to automatically begin recording when the external equipment starts playing back. Lets you make MiniDisc recordings easily. The recording time is doubled if you record in the monaural mode. Comes with a monaural long-recording mode which doubles the recording time. Best suited for recording monaural broad- casts or talk programmes. Track selection with a jog dialA jog dial makes it much easier to control the MD unit. It is easy to select track numbers or enter characters. Timer function/date stamp functionIf the unit is used with other equipment that also has a timer function, timer recording and timer playback are possible. Also, the year, month, day, and time are automatically recorded on the MiniDisc. PRECAUTIONS nGeneral lDo not use oil, solvents, petrol, paint thinners or insecticides on the unit. lDo not expose the unit to moisture, to temperatures higher than 60 oC (140 oF) or to extreme low temperatures. lKeep the unit away from direct sunlight, strong magnetic fields, excessive dust, humidity and electronic/electrical equipment (home computers, facsimiles, etc.) which generates electrical noise. lHold the AC power plug by the head when removing it from the AC outlet, since pulling the jack can damage internal wires. lNever open the cabinet. If a foreign object drops into the set, contact your dealer. lUse the unit on a firm, level surface free from vibration, and do not place anything on the top of the unit. lIf the unit does not work properly while in use, press the POWER button to turn the power off, then disconnect the AC power cord from the AC outlet. Plug the AC power cord back in, and then press the POWER button to turn the power on. lIf a lightning storm is taking place near you, it is suggested that you disconnect the AC power cord from the AC outlet for safety. Warning:The voltage used must be the same as that specified on this unit. Using this product with a higher voltage than that which is specified is dangerous and may result in a fire or other type of accident causing damage. SHARP will not be held responsible for any damage resulting from use of this unit with a voltage other than that which is specified. nInstallation location Do not install the unit in the following places. Otherwise, it may cause trouble or accidents. Places exposed to vibration Places exposed to direct sun- light for many hoursHot places Extremely cold places lPlaces exposed to high humidity. lPlaces exposed to excessive dust. lPoorly ventilated places. lPlaces exposed to water, for example, a bathroom. lPlaces near objects which generate magnetism or electric noise. nCondensation In the following cases, condensation (water droplets) may form inside of the unit (optical section). lJust after lighting a gas stove. lWhen the unit is put in a room where steam or moisture is present. lWhen the unit is carried from a cool place (room) to a warm room. MD-R2 2

Page 2

FEATURES DAT tapes can be digitally recorded directly onto a MiniDisc. The MiniDisc unit has a built-in sampling rate convertor which allows the unit to be connected to various types of digital equipment. You can record from a large variety of digital formats. Supports various types of digital/analog equipmentTwo digital input jacks and two analog input jacks are built in. They allow the unit to be connected to stereos or head- phone stereos. Recordings start automatically when the external sound source starts to produce sound. Comes with a sound synchro recording function, which allows the unit to automatically begin recording when the external equipment starts playing back. Lets you make MiniDisc recordings easily. The recording time is doubled if you record in the monaural mode. Comes with a monaural long-recording mode which doubles the recording time. Best suited for recording monaural broad- casts or talk programmes. Track selection with a jog dialA jog dial makes it much easier to control the MD unit. It is easy to select track numbers or enter characters. Timer function/date stamp functionIf the unit is used with other equipment that also has a timer function, timer recording and timer playback are possible. Also, the year, month, day, and time are automatically recorded on the MiniDisc. PRECAUTIONS nGeneral lDo not use oil, solvents, petrol, paint thinners or insecticides on the unit. lDo not expose the unit to moisture, to temperatures higher than 60 oC (140 oF) or to extreme low temperatures. lKeep the unit away from direct sunlight, strong magnetic fields, excessive dust, humidity and electronic/electrical equipment (home computers, facsimiles, etc.) which generates electrical noise. lHold the AC power plug by the head when removing it from the AC outlet, since pulling the jack can damage internal wires. lNever open the cabinet. If a foreign object drops into the set, contact your dealer. lUse the unit on a firm, level surface free from vibration, and do not place anything on the top of the unit. lIf the unit does not work properly while in use, press the POWER button to turn the power off, then disconnect the AC power cord from the AC outlet. Plug the AC power cord back in, and then press the POWER button to turn the power on. lIf a lightning storm is taking place near you, it is suggested that you disconnect the AC power cord from the AC outlet for safety. Warning:The voltage used must be the same as that specified on this unit. Using this product with a higher voltage than that which is specified is dangerous and may result in a fire or other type of accident causing damage. SHARP will not be held responsible for any damage resulting from use of this unit with a voltage other than that which is specified. nInstallation location Do not install the unit in the following places. Otherwise, it may cause trouble or accidents. Places exposed to vibration Places exposed to direct sun- light for many hoursHot places Extremely cold places lPlaces exposed to high humidity. lPlaces exposed to excessive dust. lPoorly ventilated places. lPlaces exposed to water, for example, a bathroom. lPlaces near objects which generate magnetism or electric noise. nCondensation In the following cases, condensation (water droplets) may form inside of the unit (optical section). lJust after lighting a gas stove. lWhen the unit is put in a room where steam or moisture is present. lWhen the unit is carried from a cool place (room) to a warm room. MD-R2 2
