MD-MT20H/16E Ð 2 Ð Figure 2-1 Figure 2-2 Precaution to be taken when replacing and servicing the Laser Pickup. The AEL (Accessible Emission Level) of Laser Power Output for this model is specified to be lower than Class I Requirements. However, the following precautions must be observed during servicing to protect your eyes against exposure to the laser beam. (1) When the cabinet has been removed, the power is turned on without a compact disc, and the Pickup is on a position outer than the lead-in position, the Laser will light for several seconds to detect a disc. Do not look into the Pickup Lens. (2) The Laser Power Output of the Pickup inside the unit and replacement service parts have already been adjusted prior to shipping. (3) No adjustment to the Laser Power should be attempted when replacing or servicing the Pickup. (4) Under no circumstances look directly into the Pickup Lens at any time. (5) CAUTION - Use of controls or adjustments, or performance of procedures other than those specified herein may result in hazardous radiation exposure. SAFETY PRECAUTION FOR SERVICE MANUAL VARO ! Avattaessa ja suojalukitus ohitettaessa olet alttiina nŠkymŠttšmŠlle lasersŠteilylle. €lŠ katso sŠteeseen. VARNING! Osynlig laserstralning nŠr denna del Šr šppnad och spŠrren Šr urkopplad. Betrakta ej strŠlen. Precaution to be taken when replacing and servicing the laser pickup. The following precautions must be observed during servicing to protect your eyesagainst exposure to the laser. Warning of possible eye damage when repairing: If the AC adaptor or batteries are connected when the top houising (disc cover) of the unit is removed, and the PLAY key is pressed, the laser will light up during docus access (2-3 seconds). (Fig. 2-1) During the operation, the laser will lesk from the opening btween the magnetic head and the mechanical chassis (Fig. 2-2). In order to protect your eyes, you most not look at the laser durnd repaor. Before repaoring be sure to disconnect the AC adaptor and remove the batteries. (For U.K.) (For Europe) Laser Diode Properties lMaterial: GaAlAs lWavelength: 785 nm lPulse time: Read mode: 0.8 mW Continuous Write mode: max 10 mW 0.5S min cycle 1.5S Repetition VAROITUS! LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄ KÄYTTÖOHJEESSA MAINITULLA TAVALLA SAATTAA ALTISTAA KÄYTTÄJÄN TURVALLISUUSLUOKAN 1 YLITTÄVÄLLE NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE. VARNING - OM APPARATEN ANVÄNDS PÅ ANNAT SÄTT ÄN I DENNA BRUKSANVISNING SPECIFICERAS. KAN ANVÄNDAREN UTSÄTTAS FÖR OSYNLIG LASERSTRÅLNING, SOM ÖVERSKRIDER GRÄNSEN FÖR LASERKLASS 1. LASER KLASSE 1 LUOKAN 1 LASERLAITE KLASS 1 LASERAPPARAT Magnet Head Lasar Beam Optical Pick-Up Main PWB Spindle motor Mechanism Chassis Magnet head Optical pick-upTop Cabinet
