Page 1

MD-C2H

SHARP PARTS GUIDE

MODEL MD-CZH

HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following information.
1. MODEL NUMBER 2. REF. No.
3- PART NO- 4- DESCRIPTION For location of SHARP Parts Distributor,
Please call Toll-Free;
1-800-BE-SHARP

For U.S.A. only
Contact your nearest SHARP Parts Distributor to order.

t MARK: SPARE PARTS-DELIVERY SECTION

Explanation of capacitors/resistors parts codes fi

Resistors
Ceramic type VRD
Ceramic type VHS

Capacitors
vcc
VCK

. Carbon-film type
. Carbon-film type

VCT Semiconductor type VFlN . Metal-film type

VC - - M Cylindrical type (without lead wire) VFl - - MF. . Cylindrical type (without lead wire)

VC - - MN.. Cylindrical type (without lead wire) VFt - - MN. . Cylindrical type (without lead wire)

VC - - TV.. Square type (without lead wire) VR - - TV .. . Square type (without lead Wire)

VC - - TQ .. Square type (without lead wire) VR - - TQ . . Square type (without lead wire)

VC - - CY .. Square type (without lead wire) VR - - CY . . Square type (without lead wire)

VC - - CZ Square type (Without lead wire) VR - - CZ . . Square type (without lead wire)

VC - - - - J .. The 13th character represents capacity difference. VFl - - - J .. The 13th character represents error.
("J" i5%, "K"i10%, "M flOVu, "N" i30%, ("J" i5%, "F"i1%, "D" i0.5%.)

"C" i025 pF, "D" $0.5 pF, 2" +80-20%.)
If there are no indications for other parts, the resistors are 5%
If there are no indications for the electrolytic capacitors, error is i20%. carbon-film type.

NOTE:
Parts marked with A are important for maintaining the safety of the set
Be sure to replace parts with specified ones for maintaining the safety and performance of the set.
