Page 1
SPECIAL NOTES
lRecording and playback of any material may require
consent, which SHARP is unable to give. Please refer
particularly to the provisions of the Copyright Act 1956,
the Dramatic and Musical Performers Protection Act
1958, the Performers Protection Acts 1963 and 1972 and
to any subsequent statutory enactments and orders.
NOTE FOR USERS IN THE U.K.
SERVICE INFORMATION
In the unlikely event of your equipment requiring repair,
please contact the dealer or supplier from whom it was
purchased. Where this is not possible, please contact the
telephone number listed below. You will then be given
details of how to obtain service.
- 0345-125387 -
Please note; all calls will be charged at local rate.
Certain replacement parts and accessories may be ob-
tained from our main parts distributor.
WILLOW VALE ELECTRONICS LTD.
In the unlikely event of this equipment requiring repair
during the guarantee period, you will need to provide
proof of the date of purchase to the repairing company.
Please keep your invoice or receipt, which is supplied at
the time of purchase. The mains lead of this product is fitted with a non-rewire-
able (moulded) plug incorporating a 3A fuse. Should the
fuse need to be replaced, a BSI or ASTA approved BS
1362 fuse marked or and of the same rating as
above, which is also indicated on the pin face of the plug
must be used.
Always refit the fuse cover after replacing the fuse. Never
use the plug without the fuse cover fitted.
In the unlikely event of the socket outlet in your home
not being compatible with the plug supplied, cut-off the
mains plug and fit an appropriate type.
DANGER:
The fuse from the cut-off plug should be removed and
the cut-off plug destroyed immediately and disposed of
in a safe manner.
Under no circumstances should the cut-off plug be in-
serted elsewhere into a 13A socket outlet as a serious
electric shock may occur.
To fit an appropriate plug to the mains lead, follow the
instructions below:
IMPORTANT:
The wires in the mains lead are coloured in accordance
with the following code:
Blue : Neutral
Brown : Live
As the colours of the wires in the mains lead of this
product may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
l The wire which is coloured blue must be connected to
the plug terminal which is marked N or coloured black.
l The wire which is coloured brown must be connected
to the plug terminal which is marked L or coloured red.Ensure that neither the brown nor the blue wire is con-
nected to the earth terminal in your three pin plug.
Before replacing the plug cover, make sure that:
l If the new fitted plug contains a fuse, its value is the
same as that removed from the cut-off plug.
l The cord grip is clamped over the sheath of the mains
lead and not simply over the lead wires.
IF YOU HAVE ANY DOUBT, CONSULT A QUALIFIED
ELECTRICIAN. MANCHESTER 0161-682-1415
READING 01189-876444
l This equipment complies with the requirements of
Directives 89/336/EEC and 73/23/EEC as amended by
93/68/EEC. HK
lWhen the ON/STAND-BY button is set at STAND-BY
position, mains voltage is still present inside the unit.
When the ON/STAND-BY button is set at STAND-BY
position, the unit may be brought into operation by the
timer mode or remote control.
Warning:
This unit contains no user serviceable parts. Never remove
covers unless qualified to do so. This unit contains danger-
ous voltages, always remove mains plug from the socket
before any service operation and when not in use for a long
period.lUS and foreign patents licensed from Dolby Laboratories
Licensing Corporation.
MD-C2H(SUK) TINSE0238AWZZCAUTION
Use the MD mini system only in accordance with the instruc-
tions given in this manual and do not attempt to interfere
with the interlock switch or make any other adjustment as
this may result in exposure to hazardous radiation.
1
Page 1
SPECIAL NOTES
lRecording and playback of any material may require
consent, which SHARP is unable to give. Please refer
particularly to the provisions of the Copyright Act 1956,
the Dramatic and Musical Performers Protection Act
1958, the Performers Protection Acts 1963 and 1972 and
to any subsequent statutory enactments and orders.
NOTE FOR USERS IN THE U.K.
SERVICE INFORMATION
In the unlikely event of your equipment requiring repair,
please contact the dealer or supplier from whom it was
purchased. Where this is not possible, please contact the
telephone number listed below. You will then be given
details of how to obtain service.
- 0345-125387 -
Please note; all calls will be charged at local rate.
Certain replacement parts and accessories may be ob-
tained from our main parts distributor.
WILLOW VALE ELECTRONICS LTD.
In the unlikely event of this equipment requiring repair
during the guarantee period, you will need to provide
proof of the date of purchase to the repairing company.
Please keep your invoice or receipt, which is supplied at
the time of purchase. The mains lead of this product is fitted with a non-rewire-
able (moulded) plug incorporating a 3A fuse. Should the
fuse need to be replaced, a BSI or ASTA approved BS
1362 fuse marked or and of the same rating as
above, which is also indicated on the pin face of the plug
must be used.
Always refit the fuse cover after replacing the fuse. Never
use the plug without the fuse cover fitted.
In the unlikely event of the socket outlet in your home
not being compatible with the plug supplied, cut-off the
mains plug and fit an appropriate type.
DANGER:
The fuse from the cut-off plug should be removed and
the cut-off plug destroyed immediately and disposed of
in a safe manner.
Under no circumstances should the cut-off plug be in-
serted elsewhere into a 13A socket outlet as a serious
electric shock may occur.
To fit an appropriate plug to the mains lead, follow the
instructions below:
IMPORTANT:
The wires in the mains lead are coloured in accordance
with the following code:
Blue : Neutral
Brown : Live
As the colours of the wires in the mains lead of this
product may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
l The wire which is coloured blue must be connected to
the plug terminal which is marked N or coloured black.
l The wire which is coloured brown must be connected
to the plug terminal which is marked L or coloured red.Ensure that neither the brown nor the blue wire is con-
nected to the earth terminal in your three pin plug.
Before replacing the plug cover, make sure that:
l If the new fitted plug contains a fuse, its value is the
same as that removed from the cut-off plug.
l The cord grip is clamped over the sheath of the mains
lead and not simply over the lead wires.
IF YOU HAVE ANY DOUBT, CONSULT A QUALIFIED
ELECTRICIAN. MANCHESTER 0161-682-1415
READING 01189-876444
l This equipment complies with the requirements of
Directives 89/336/EEC and 73/23/EEC as amended by
93/68/EEC. HK
lWhen the ON/STAND-BY button is set at STAND-BY
position, mains voltage is still present inside the unit.
When the ON/STAND-BY button is set at STAND-BY
position, the unit may be brought into operation by the
timer mode or remote control.
Warning:
This unit contains no user serviceable parts. Never remove
covers unless qualified to do so. This unit contains danger-
ous voltages, always remove mains plug from the socket
before any service operation and when not in use for a long
period.lUS and foreign patents licensed from Dolby Laboratories
Licensing Corporation.
MD-C2H(SUK) TINSE0238AWZZCAUTION
Use the MD mini system only in accordance with the instruc-
tions given in this manual and do not attempt to interfere
with the interlock switch or make any other adjustment as
this may result in exposure to hazardous radiation.
1
Page 2
HK
PRECAUTIONS
n General
lPlease make sure that the unit is positioned in a well ven-
tilated area and that there is at least 10 cm (4") of free
space along the sides and back. There must also be a
minimum of 20 cm (8") of free space on the top of the
unit.
lDo not use oil, solvents, petrol, paint thinners or insec-
ticides on the unit.
lDo not expose the unit to moisture, to temperatures higher
than 60ÆC (140ÆF) or to extreme low temperatures.
lKeep the unit away from direct sunlight, strong magnetic
fields, excessive dust, humidity and electronic/electrical
equipment (home computers, facsimiles, etc.) which gener-
ates electrical noise.
lHold the AC power plug by the head when removing it
from the AC socket, as pulling the lead can damage in-
ternal wires.
lWhen cleaning the heads, pinch roller, etc, remove the
AC power plug from the wall socket as the unit contains
high voltages.
Do not remove the outer cover, as this may result in elec-
tric shock. Refer internal service to your local SHARP ser-
vice facility.
lUse the unit on a firm, level surface free from vibration,
and do not place anything on the top of the unit.
lIf the unit malfunctions whilst in use, press the ON/STAND-
BY button to enter the stand-by mode, then disconnect
the AC power lead from the AC socket. Plug the AC power
lead back in, and then press the ON/STAND-BY button to
turn the power on.
lIf an electrical storm is taking place near you, it is sug-
gested that you disconnect the AC power lead from the
AC socket for safety.
Warning:
The voltage used must be the same as that specified on this
unit. Using this product with a higher voltage other than which
is specified is dangerous and may result in a fire or other
type of accident causing damage. SHARP will not be held
responsible for any damage resulting from use of this unit
with a voltage other than that which is specified.
n Volume control
The sound level at a given volume setting depends on a
combination of speaker efficiency, location and various other
factors.
It is advisable to avoid exposure to high volume levels, which
occur whilst turning the unit on with the volume control set-
ting up high, or whilst continually listening at high volumes.
n Condensation
Sudden temperature changes, storage or operation in an ex-
tremely humid environment may cause condensation inside
the cabinet (CD pickup, MD pickup, tape heads, etc.) or on
the transmitter LED on the remote control.
Condensation can cause the unit to malfunction.
If this happens, leave the power on with no disc (or cassette)
in the unit until normal playback is possible (about 1 hour).
Wipe off any condensation on the transmitter LED with a soft
cloth before operating the unit.
n Care of compact discs
Compact discs are fairly resistant to damage, however mis-
tracking can occur due to an accumulation of dirt on the disc
surface.
Follow the guidelines below for maximum enjoyment from
your CD collection and player.
lDo not write on either side of the disc, particularly the
non-label side. Signals are read from the non-label side.
Do not mark this surface.
lKeep your discs away from direct sunlight, heat, and ex-
cessive moisture.
lAlways hold the CDs by the edges. Fingerprints, dirt, or
water on the CDs can cause noise or mistracking. If a CD
is dirty or does not play properly, clean it with a soft, dry
cloth, wiping straight out from the centre, along the radius.
NO
YES
Correct
n Cassette tape
lFor playback, use normal or low-noise tape for the best
sound. (Metal or CrO 2 tape is not recommended.)
For recording, use only normal tape.
lDo not use C-120 tapes, tapes with large diameter reels,
or poor-quality tapes, as they may cause malfunctions.
lBefore loading a tape into the cassette compartment,
tighten the slack with a pen or pencil.
lCassettes have removable tabs which prevent accidental
recording or erasing from taking place. Removing the tab
will protect the corresponding side from being erased.
Cover the tab holes with adhesive tape to erase or record
again.
Side A (1)
Tab for side B (2)Tab for side A (1)
MD-C2H(SUK) TINSE0238AWZZ
2
Page 2
HK
PRECAUTIONS
n General
lPlease make sure that the unit is positioned in a well ven-
tilated area and that there is at least 10 cm (4") of free
space along the sides and back. There must also be a
minimum of 20 cm (8") of free space on the top of the
unit.
lDo not use oil, solvents, petrol, paint thinners or insec-
ticides on the unit.
lDo not expose the unit to moisture, to temperatures higher
than 60ÆC (140ÆF) or to extreme low temperatures.
lKeep the unit away from direct sunlight, strong magnetic
fields, excessive dust, humidity and electronic/electrical
equipment (home computers, facsimiles, etc.) which gener-
ates electrical noise.
lHold the AC power plug by the head when removing it
from the AC socket, as pulling the lead can damage in-
ternal wires.
lWhen cleaning the heads, pinch roller, etc, remove the
AC power plug from the wall socket as the unit contains
high voltages.
Do not remove the outer cover, as this may result in elec-
tric shock. Refer internal service to your local SHARP ser-
vice facility.
lUse the unit on a firm, level surface free from vibration,
and do not place anything on the top of the unit.
lIf the unit malfunctions whilst in use, press the ON/STAND-
BY button to enter the stand-by mode, then disconnect
the AC power lead from the AC socket. Plug the AC power
lead back in, and then press the ON/STAND-BY button to
turn the power on.
lIf an electrical storm is taking place near you, it is sug-
gested that you disconnect the AC power lead from the
AC socket for safety.
Warning:
The voltage used must be the same as that specified on this
unit. Using this product with a higher voltage other than which
is specified is dangerous and may result in a fire or other
type of accident causing damage. SHARP will not be held
responsible for any damage resulting from use of this unit
with a voltage other than that which is specified.
n Volume control
The sound level at a given volume setting depends on a
combination of speaker efficiency, location and various other
factors.
It is advisable to avoid exposure to high volume levels, which
occur whilst turning the unit on with the volume control set-
ting up high, or whilst continually listening at high volumes.
n Condensation
Sudden temperature changes, storage or operation in an ex-
tremely humid environment may cause condensation inside
the cabinet (CD pickup, MD pickup, tape heads, etc.) or on
the transmitter LED on the remote control.
Condensation can cause the unit to malfunction.
If this happens, leave the power on with no disc (or cassette)
in the unit until normal playback is possible (about 1 hour).
Wipe off any condensation on the transmitter LED with a soft
cloth before operating the unit.
n Care of compact discs
Compact discs are fairly resistant to damage, however mis-
tracking can occur due to an accumulation of dirt on the disc
surface.
Follow the guidelines below for maximum enjoyment from
your CD collection and player.
lDo not write on either side of the disc, particularly the
non-label side. Signals are read from the non-label side.
Do not mark this surface.
lKeep your discs away from direct sunlight, heat, and ex-
cessive moisture.
lAlways hold the CDs by the edges. Fingerprints, dirt, or
water on the CDs can cause noise or mistracking. If a CD
is dirty or does not play properly, clean it with a soft, dry
cloth, wiping straight out from the centre, along the radius.
NO
YES
Correct
n Cassette tape
lFor playback, use normal or low-noise tape for the best
sound. (Metal or CrO 2 tape is not recommended.)
For recording, use only normal tape.
lDo not use C-120 tapes, tapes with large diameter reels,
or poor-quality tapes, as they may cause malfunctions.
lBefore loading a tape into the cassette compartment,
tighten the slack with a pen or pencil.
lCassettes have removable tabs which prevent accidental
recording or erasing from taking place. Removing the tab
will protect the corresponding side from being erased.
Cover the tab holes with adhesive tape to erase or record
again.
Side A (1)
Tab for side B (2)Tab for side A (1)
MD-C2H(SUK) TINSE0238AWZZ
2
