Page 1
I_:Ijjjj 4%
GX-CD30/30C/130/13OC
SHARP SERVICE MANUAL
N0. S3607GX-CD130
GX-CD30
GX-CD30C
GX-CD130
GX-CD130C
Illustration: GX-CD13O
COMPACT
El - In Ihe interests of user-saIer the set should be restored to its
DIGITAL AUDIO original condition and only parts identical to those specified
should be used.
CONTENTS
IMPORTANT SERVICE NOTES (FOR GX-CD30/130 ONLY) .....
SPECIFICATIONS ......
NAMES OF PARTS
DISASSEMBLY ...........
REMOVING AND REINSTALLING THE MAIN PARTS
ADJUSTMENT ...........................................
TROUBLESHOOTING (CD SECTION) .
NOTES ON SCHEMATIC DIAGRAM
TYPES OF TRANSISTOR ..
BLOCK DIAGRAM ..............
SCHEMATIC DIAGRAM /W|R|NG SIDE OF P.W.BOARD ..
WAVEFORMS OF CD CIRCUIT
FUNCTION TABLE OF IC ..............
PARTS GUIDE/EXPLODED VIEW
PACKING OF THE SET (FOR GX-CD30/130 ONLY)
DIFFERENCE BETWEEN GX-CD30/3OC AND GX-CD130/130C
GX-CDSO/SOC GX-CD130/130C
REMOTE None Used
CONTROL
X-BASS None Used
SHARP CORPORATION
SHARP ELECTRONICS CORPORATION
Service Headquarters: Sharp Plaza, Mahwah, New Jersey 07430-2135
Page 1
I_:Ijjjj 4%
GX-CD30/30C/130/13OC
SHARP SERVICE MANUAL
N0. S3607GX-CD130
GX-CD30
GX-CD30C
GX-CD130
GX-CD130C
Illustration: GX-CD13O
COMPACT
El - In Ihe interests of user-saIer the set should be restored to its
DIGITAL AUDIO original condition and only parts identical to those specified
should be used.
CONTENTS
IMPORTANT SERVICE NOTES (FOR GX-CD30/130 ONLY) .....
SPECIFICATIONS ......
NAMES OF PARTS
DISASSEMBLY ...........
REMOVING AND REINSTALLING THE MAIN PARTS
ADJUSTMENT ...........................................
TROUBLESHOOTING (CD SECTION) .
NOTES ON SCHEMATIC DIAGRAM
TYPES OF TRANSISTOR ..
BLOCK DIAGRAM ..............
SCHEMATIC DIAGRAM /W|R|NG SIDE OF P.W.BOARD ..
WAVEFORMS OF CD CIRCUIT
FUNCTION TABLE OF IC ..............
PARTS GUIDE/EXPLODED VIEW
PACKING OF THE SET (FOR GX-CD30/130 ONLY)
DIFFERENCE BETWEEN GX-CD30/3OC AND GX-CD130/130C
GX-CDSO/SOC GX-CD130/130C
REMOTE None Used
CONTROL
X-BASS None Used
SHARP CORPORATION
SHARP ELECTRONICS CORPORATION
Service Headquarters: Sharp Plaza, Mahwah, New Jersey 07430-2135
Page 1
I_:Ijjjj 4%
GX-CD30/30C/130/13OC
SHARP SERVICE MANUAL
N0. S3607GX-CD130
GX-CD30
GX-CD30C
GX-CD130
GX-CD130C
Illustration: GX-CD13O
COMPACT
El - In Ihe interests of user-saIer the set should be restored to its
DIGITAL AUDIO original condition and only parts identical to those specified
should be used.
CONTENTS
IMPORTANT SERVICE NOTES (FOR GX-CD30/130 ONLY) .....
SPECIFICATIONS ......
NAMES OF PARTS
DISASSEMBLY ...........
REMOVING AND REINSTALLING THE MAIN PARTS
ADJUSTMENT ...........................................
TROUBLESHOOTING (CD SECTION) .
NOTES ON SCHEMATIC DIAGRAM
TYPES OF TRANSISTOR ..
BLOCK DIAGRAM ..............
SCHEMATIC DIAGRAM /W|R|NG SIDE OF P.W.BOARD ..
WAVEFORMS OF CD CIRCUIT
FUNCTION TABLE OF IC ..............
PARTS GUIDE/EXPLODED VIEW
PACKING OF THE SET (FOR GX-CD30/130 ONLY)
DIFFERENCE BETWEEN GX-CD30/3OC AND GX-CD130/130C
GX-CDSO/SOC GX-CD130/130C
REMOTE None Used
CONTROL
X-BASS None Used
SHARP CORPORATION
SHARP ELECTRONICS CORPORATION
Service Headquarters: Sharp Plaza, Mahwah, New Jersey 07430-2135
Page 2
l _:I:|:|:|:l
GX-CD30/30C/130/130C
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
IMPORTANT SERVICE NOTES (FOR GX-CD30/130 ONLY)
BEFORE RETURNING THE AUDIO PRODUCT
(Fire & Shock Hazard)
Before returning the audio product to the user, perform the
following safety checks.
1. Inspect all lead dress to make certain that leads are not VTVM
pinched orthat hardware is not lodged between the chassis 0AC SCALEO
and other metal parts in the audio product.
2. Inspect all protective devices such as insulating materials, 1.5k ohms
cabinet, terminal board, adjustment and compartment
covers or shields, mechanical insulators etc.
3. To be sure that no shock hazard exists, check for leakage
current in the following manner.
10W
-l
Plug the AC line cord directly into a 120 volt AC outlet. 015 H F
Using two clip leads, connect a 1.5k ohm, 10 watt resistor TEST pRoBE CONNECT TO
paralleled by a 0.15pF capacitor in series with all exposed TO EXPOSED KNOWN EARTH
metal cabinet parts and a known earth ground, such as METAL PARTS
R ND
conduit or electrical ground connected to earth ground. G 0U
" Use a VTVM or VOM with 1000 ohm per volt, or higher,
sensitivity to measure the AC voltage drop across the
resistor (See diagram).
Connect the resistor connection to all exposed metal parts
having a return path to the chassis (antenna, metal cabinet,
screw heads, knobs and control shafts, escutcheon, etc.)
and measure the AC voltage drop across the resistor.
AllcheckmustberepeatedwiththeAClinecord plugconnection
reversed.
Any reading of 0.3 volt RMS (this corresponds to 0.2 milliamp.
AC.) or more is excessive and indicates a potential shock
hazard which must be corrected before returning the audio
product to the owner.
SPECIFICATIONS
0 General 0 Compact disc player
Power source: AC 120V, 60 Hz Disc: Compact disc
Power consumption:
Output power:
(30/130)
Output power:
(BOO/13°C)
Output terminal:
Dimensions:
Weight:
0 Radio
Frequency range:
0 Tape recorder
Frequency response:
Signal/noise ratio:
Wow and flitter:
Motor:
Bias system:
Erase system:
DC 12V I "D" size (UM/SUM-1 , R20
or HP-2) battery x 8]
25 W
FTC; 2.5 W minimum RMS per
channel into 6 ohms from 100 Hz to
20 kHz with no more than 10 % total
harmonic distortion.
RMS; 3.5 W per channel at 1 kHz,
10 % total harmonic distortion.
(AC operation)
RMS: 7 W (3.5 W + 3.5 W)
(AC operation, 10 % T.H.D.)
Headphones; 16 - 50 ohms
(recommended; 32 ohms)
Width; 12" (304 mm)
Height; 9-1/4 (234 mm)
Depth; 8-9/16" (216 mm)
7.1 lbs. (3.2 kg) without batteries
FM; 87.6 - 108 MHZ
AM; 530 - 1,702 kHz
50 - 14,000 Hz (Normal tape)
50dB (TAPE 1 , recording/playback)
55 dB (TAPE 2, playback)
0.25 % (WRMS)
DC 12 V electric governor
AC bias
AC erase
Signal readout:
Audio channels:
Quantization:
Filter:
D/A converter:
Wow and flutter:
0 Speaker
Type:
Speakers:
Maximum input power:
Impedance:
Dimensions:
Weight:
Non-contact, 3-beam semi-
conductor laser pickup
2
16-bit linear
4-tims oversampling digital filter
1-bit D/A converter
Unmeasurable
(less than 0.001% W. peak)
2-way bass-reflex type
4" (10 cm) woofer x 2
Tweeter x 2
5 W
6 ohms
Width; 7-5/16" (185 mm)
Height; 8-11/16" (220 mm)
Depth; 5-15/16" (150 mm)
2.2 lbs. (1.0 kg) leach
prior notice.
Specifications for this model are subject to change without
