CD-XP200/CD-XP2200

SHARP SERVICE MANUAL

No. S1206CDXP200/

MINI COMPONENT SYSTEM

MODEL CD-XP200

CD-XP200 Mini Component System consisting of CD-XPZOO
(main unit) and CP-XP200 (speaker system).

MINI COMPONENT SYSTEM
MODEL CD-XP2200
@COMMCT CD-XP2200 Mini Component System consisting of CD-XP2200
(main unit) and CP-XP2200 (speaker system).
WISE Gem-raw leg

- In the interests of user-salety the set should be restored to its
original condition and only parts identical to those specified be
used.

/- CONTENTS -\

IMPORTANT SERVICE NOTES (FOR U.S.A. ONLY)
SPECIFICATIONS
NAMES OF PARTS ..
OPERATION MANUAL
QUICK GUIDE (FOR U.S.A. ONLY) ..
DISASSEMBLY ..................................
REMOVING AND REINSTALLING THE MAIN PARTS.
ADJUSTMENT ...................................
NOTES ON SCHEMATIC DIAGRAM
TYPES OF TRANSISTOR AND LED.
BLOCK DIAGRAM .............................
SCHEMATIC DIAGRAM / WIRING SIDE OF P.W.BOARD
VOLTAGE ...................................
WAVEFORMS OF CD CIRCUIT.
TROUBLESHOOTING .....
FUNCTION TABLE OF IC
FL DISPLAY .....................
REPLACEMENT PARTS LIST/EXPLODED VIEW
PACKING OF THE SET (FOR U.S.A. ONLY)

This document has been published to be used

SHARP CORPORATION for after sales service only.

The contents are subject to change without notice.
