CD-XP125V
SAFETY PRECAUTION FOR SERVICE MANUAL
WARNINGS
THE AEL (ACCESSIBLE EMISSION LEVEL) OF THE LASER POWER OUTPUT IS LESS THAN CLASS 1 BUT THE LASER
COMPONENT IS CAPABLE OF EMITTING RADIATION EXCEEDING THE LIMIT FOR CLASS 1. THEREFORE IT IS
IMPORTANT THATTHE FOLLOWING PRECAUTIONS ARE OBSERVED DURING SERVICING TO PROTECT YOUR EYES
AGAINST EXPOSURE TO THE LASER BEAM.
1-WHEN THE CABINET IS REMOVED, THE POWER IS TURNED ON WITHOUTA COMPACT DISC IN POSITION AND THE
PICKUP IS ON THE OUTER EDGE THE LASER WILL LIGHT FOR SEVERAL SECONDS TO DETECT A DISC. DO NOT
LOOK INTO THE PICKUP LENS.
2-THE LASER POWER OUTPUT OF THE PICKUP UNIT AND REPLACEMENT SERVICE PARTS ARE ALL FACTORY
PRESET BEFORE SHIPMENT.
DO NOT ATTEMPT TO READJUST THE LASER PICKUP UNIT DURING REPLACEMENT OR SERVICING.
3-UNDER NO CIRCUMSTANCES STARE INTO THE PICKUP LENS AT ANY TIME.
4-CAUTION-USE OF CONTROLS OR ADJUSTMENTS, OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
Laser Diode Properties
Material: GaAlAs
Wavelength: 780 nm
Emission Duration: continuous
Laser Output: max. 0.6 mW
mriun llVlSIBLE uszn murmn WMEH am.
an nnr SYAIE mm am an vrzw anEEYLY wmi
nmm msrnvnzm.
wuwnuruusmmnnz tusxsmutunn Wm mm
aznmn. mm Ill IllE mmvun 5mm um
mm Mil UPYISENEM HILFSMlYYELI snucursu. WWIIIIIIII.
Arvznmu-nnvnu LASER IIVlSlBLE Ell us unwmun: ~ » 335le l III
it! Ms wzsannzn LE nuscw IIIRECIEMEM nv me as: uh. IIIIII Wm
llleRllllElflS ninn l WW
VOLTAGE SELECTION
Before operating the unit on mains. check the preset voltage. If the voltage is different from your local voltage, adjust the voltage
as follows.
Turn the selectorwith a screwdriver until the appropriate voltage number appears in the window (1 10 V. 127 V, 220 V or 230 V » 240 V AC).
AC POWER SUPPLY CORD AND AC PLUG ADAPTOR
QACCEOOOZSJOO QPLGA0250AFZZ
I»
QACCAOOOZSJOO
mm
