Page 1
SHARP SERVICE MANUAL
'I
lfilfiwepfi
DIGITAL AUDIO
Dfl-®
- Dolby noise reduction manufactured under license from Dolby Labora-
tories Licensing Corporation.
- DOLBY and the double-D symbol DC! are trademarks of Dolby La-
boratories Lice sing Corporation,
S3127CD8600XG
co-ssooxmw
CP-3600X(GY)
, Active Servo
Technology NOTE:
When operating this unit. prepare both the CD and tape deck
units. This unit does not operate properly with only one unit.
When using speakers, be sure to use this units speakers If
other speakers are used, damage may occur.
- in the interests of user-safety the setshould be restored to its original
condition and only parts identical to those specified be used.
/- lNDEX TO CONTENTS -\
Page
SPECIFICATIONS ......................................................... 2
NAMES OF PARTS ........ . . .................................. 3-6
OPERATION MANUAL ............................................. 7-1 4
DISASSEMBLY ....................................................... 15-18
REMOVING AND REINSTALLING THE MAIN PARTS ........................ 19,20
BLOCK DIAGRAM ..................................................... 21-25
ADJUSTMENT ....................................................... 26-29
TROUBLESHOOTING (CD SECTION) .................................... 30-34
FUNCTION TABLE OF IC ............................................... 35-45
LCD SEGMENT ....................................................... 45-47
AC POWER SUPPLY CORD ............................................... 4B
SCHEMATIC DIAGRAM / WIRING SIDE OF P.W. BOARD .................... 49-74
NOTES ON SCHEMATIC DIAGRAM ........................................ 75
WAVE FORMS OF CD CIRCUIT ............................................ 76
EXPLODED VIEW ..................................................... 77-82
REPLACEMENT PARTS LIST .......................................... 83-100
SHARP CORPORATION
