CD-S450 H/ E

CP-S450

® FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT; PLEASE REFER
TO THE OPERATION MANUAL.

DD-

Recording and playback of any material may require consent

- Dolby noise reduction manufactured under license from which SHARP is unable to give. Please refer particularly to the

Dolby Laboratories Licensing Corporation. provisions of Copyright Act 1956, the Dramatic and Musical Per-
. DOLBY and the double-D symbol DU are trademarks of formers Protection Act 1956, the Performers Protection Acts 1963

Dolby Laboratories Licensing Corporation. and 1972 andto any subsequent statutory enactments and orders.

SPECIFICATIONS
l Mini component system
0 General 0 Compact disc player section
Power source: AC 230 V; 50 Hz Type: Compact disc player
(CD-S450H) Signal readout: Non-contact, 3-beam semi-
Power source: AC 240 V; 50 Hz conductor laser pickup
(CD-S450E) Error correction: CIRC (Cross Interleave Reed-
Power consumption: 400 W Solomon Code)
Dimensions: Width; 270 mm (10-5/8") Audio channels: 2
Height; 316 mm (12-7/16") Decoder: 16-bit linear quantization
Depth; 347 mm (13-11/16") Filter: 2-times oversampling digital filter and
Weight: 9.0 kg (20.0 lbs.) active filter
Frequency response: 20 - 20,000 Hz
Wow and flutter: Unmeasurable

O Amplifier section (less than 0.001% W. peak)
Output power: PMPO; 500 W (total)
(CD-S450H) MPO; 250 W (125 W + 125 W)

(DIN 45 324)(1o % T.H.D.)
RMS;160 w (80 w + so W)
(DIN 45 324)(1o % T.H.D.)
RMS;140 w (70 W + 70 W)
(DIN 45 500)(1 % T.H.D.)

Output power: MPO; 250 w (125 w + 125 W) l Speaker System
(cD-S45OE) HMS; 160 W (80 W + 80 W)
(10% T.H.D. 1 kHz, 8 ohms) Type: 2-way 16 cm (6-5/16") woofer and
Output terminals: Speakers; 8 ohms 5 cm (2") tweeter type
Headphones; 16-50 ohms Maximum input power: 130 W
(recommended; 32 ohms) Impedance: 8 ohms
Input terminals: PHONO; 2.5 mV/47 kohms Dimensions: Width: 180 mm (7-3/32")
Height; 316 mm (12-7/16")
Depth; 276.5 mm (10-7/8")
0 Tuner section Weight: 4.6 kg (10.2 lbs.)/each
Frequency range: FM; 87.5-108 MHz

SW: 5.95 - 17.9 MHZ
MW; 522-1520 kHz
LW; 153-281 kHz

0 Cassette deck section

Tape: Compact cassette tape
Bias and erasure system: AC
Tape speed: 4.76 cm/sec (1 -7/8 ips.)
Heads: TAPE-1: Playback x 1

TAPE-2: Record/playback x 1

Erase x 1

Motor: DC motor x 1
SIN ratio: Dolby NR off; 50 dB ;

Dolby NR effect; 10 dB l

(at over 5 kHz) f
Wow and flutter: 0.25 0/: (DIN 45 511)

0.15 % (WRMS)

Specifications forthis model are subject to change without prior
notice.
