CD-ESQOO/CD-ESQQ
IMPORTANT SERVICE NOTES

BEFORE RETURNING THE AUDIO PRODUCT

BEFORE RETURNING THE AUDIO PRODUCT

(Fire & Shock Hazard)

Before returning the audio product to the user, perform the following

safety checks.

1. Inspect all lead dress to make certain that leads are not pinched or
that hardware is not lodged between the chassis and other metal
parts in the audio product.

2. Inspect all protective devices such as insulating materials, cabinet,
terminal board, adiustment and compartment covers or shields,
mechanical insulators etc.

3. To be sure that no shock hazard exists, check tor leakage current in
the following manner.

Plug the AC line cord directly into a 120 volt AC outlet.

Using two clip leads, connect a 1.5 kohm, 10 watt resistor paralleled

by a 0.15 pF capacitor in series with all exposed metal cabinet parts

and a known earth ground, such as conduit or electrical ground con-
nected to earth ground.

Use a VTVM or VOM with 1000 ohm per volt, or higher, sensitivity to

measure the AC voltage drop across the resistor (See diagram).

Connect the resistor connection to all exposed metal parts having a

return path to the chassis (antenna, metal cabinet, screw heads,

knobs and control shafts, escutcheon, etc.) and measure the AC
voltage drop across the resistor.

All check must be repeated with the AC line cord plug connection
reversed.

Any reading of 0.3 volt RMS (this corresponds to 0.2 milliamp. AC.) or
more is excessive and indicates a potential shock hazard which must
be corrected before returning the audio product to the owner.

fi

VTVM
-OAC SCALE W

1.5 kohms
10 W

0.15 pF

TEST PROBE CONNECTTO

KNOWN EARTH
GROUND

TO EXPOSED
METAL PARTS
