CD-BA200

TO THE OPERATION MANUAL.

FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER

IMPORTANT SERVICE NOTES (FOR U.S.A. ONLY)

BEFORE RETURNING THE AUDIO PRODUCT

(Fire & Shock Hazard)

Before returning the audio product to the user, perform the

following safety checks.

1. Inspect all lead dress to make certain that leads are not
pinched orthat hardware is not lodged between the chassis
and other metal parts in the audio product.

. Inspect all protective devices such as insulating materials,
cabinet, terminal board, adjustment and compartment covers
or shields, mechanical insulators etc.

. To be sure that no shock hazard exists, check for leakage
current in the following manner.

* Plug the AC line cord directly into a 120 volt AC outlet.

* Using two clip leads, connect a 1.5k ohm, 10 watt resistor
paralleled by a 0.15uF capacitor in series with all exposed
metal cabinet parts and a known earth ground, such as
conduit or electrical ground connected to earth ground.

* Use a VTVM or VOM with 1000 ohm per volt, or higher,

sensitivity to measure the AC voltage drop across the

resistor (See diagram).

Connect the resistor connection to all exposed metal parts

having a return path to the chassis (antenna, metal cabinet,

screw heads, knobs and control shafts, escutcheon, etc.)
and measure the AC voltage drop across the resistor.

¢$

VTVM
-OAC SCALEO-

1 .5k ohms
10W

0.15pF

TEST PROBE
TO EXPOSED CONNECT TO
METAL PARTS KNOWN EARTH
GROUND

All check must be repeated with the AC line cord plug connection
reversed.

Any reading of 0.3 volt RMS (this corresponds to 0.2 milliamp.
AC.) or more is excessive and indicates a potential shock
hazard which must be corrected before returning the audio

product to the owner.

SPECIFICATIONS

CD-BAZOO

C General
Power source:
Power consumption:

AC 120 V, 60 Hz
185W

Dimensions: Width; 10-5/8" (270 mm)
Height; 13" (330 mm)
Depth; 14" (355 mm)

Weight: 19.2 lbs. (8.7 kg)

0 Amplifier section
Output power:
(Except for Canada)

100 watts minimum RMS per
channel into 6 ohms from 60 Hz
to 20 kHz, 10 °/o total harmonic
distortion

RMS; 200 W (100 W +100 W)

(10% T.H.D)

[Main speaker (woofer,

tweeter and super

tweeter);

80 W (40 W + 40 W),

Subwoofer;

120 W (60 W + 60W)]
Speakers; 6 ohms
Headphones; 16-50 ohms
(recommended; 32 ohms)
Video/Auxiliary (audio signal);
500 mV/47 kohms

Output power:
(For Canada)

Output terminals:

Input terminals:

0 Compact disc player section

Type: 3-disc multi-play compact disc
player

Non-contact, 3-beam semi-
conductor Iaser pickup

1-bit D/A converter

Signal readout:

D/A Converter:

Frequency response:
Dynamic range:

0 Tuner section
Frequency range:

0 Cassette deck section
Frequency response:
Signal/noise ratio:

Wow and flutter:

CP-BA200

0 Speaker section
Type:

Maximum input power
(Total):

Rated input power
(Total):

Impedance:
Dimensions:

Weight:

20 - 20,000 Hz
90 dB (1 kHz)

FM; 87.5 - 108 MHZ
AM; 530 - 1,720 kHz

50 - 14,000 Hz (Normal tape)

55 dB (TAPE 1, playback)

50 dB (TAPE 2, recording/
playback)

0.3 /o (WRMS)

4-way type [5-1/4" (13 cm) sub
woofer, 5-1/4" (13 cm) woofer,
2 (5cm) tweeter and super
tweeter]

200 W

100W

6 ohms

Width; 10-5/8" (270 mm)
Height; 13" (330 mm)
Depth; 10-3/8" (264.6 mm)
10.3 lbs. (4.7 kg)/each
