Scott PS 16 Owners Manual

Page 2

PS 16 INTRODUCTION

For over 25 years, H.Hl Scot! Inc. has been manufacrunng the ultimate in high-fidelity componenls. and we are pleased
to welcome you 10 our avergrowing family of satisfied customers. We are confidem that you and you! family WI" enioy
many years of troublefrec listening pleasure from your new SCOTT stereo turntable.

Your new SCOTT Lurnrame is a sophisticared and flexible min I! is neither complicated to inslall nor to operate.
However, to obtain optimum performance, a few moments at your time are required to read this manual in order to

become familiar with is many Ieatures and how lo use rherni

Should there be any questions which are not lully answered by this operating manml, please contain your local SCOTT
dealer, or HVH. SCOTT, INC,

BEFORE IN LLING

When inszalling Model PS 16 observe the following,

Set Model PS l6 an a place arable and free from Vibrations.

Award a place subject to direct sunligh l, or near a space heater or other hear generarmg object.
Select a place which is well venrilared With low humidiry and free from dust

Kenn rho playar system awav from the speaker systems to avoid rhe howling prolrlemsl

wwr

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE T0 RAIN DH MOISTURE.

Page 10

III. ABOUT LUBRICATIDII

'l. Lubricate the machine two or three times a year if it is used for ordinary home entertainment purpose, and once

a month if used for business purpose.

The motor shaft bearings and center spindle bearing

shank! be lubricated (See figure 12)

2. When lubricating, be careful not to contaminate
the driving roller. turntable drive drum, belt

and/or bolt guide with the oil.

If they are accidentally contaminated with the
oil, wipe them clean using with a piece of soft
cloth moistened with absolute alcohol.

DRIVING
ROLLER CENTER
/SPINDLE
MOTOR
SHAFT LUBRICATE: // SEARING
BEARING '- ' I '
Fig. 12 MOTOR

SPECIFICATIONS

TYPE:

TURNTABLE DRIVE SYSTEM:
TURNTABLE SPEED:

MOTOR:

SPEED CHANGE MECHANISM:
TURNTABLE PLATTER:

WOW AND FLUTTER:
SIGNAL T0 NOISE RATIO:

PICK-UP ARM:

EFFECTIVE ARM LENGTH:
USABLE CARTRIDGE WEIGHT:

CARTRIDGE:

FREQUENCY RESPONSE:
RECOMMENDED STYLUS PRESSURE:
OUTPUT VOLTAGE:

CHANNEL BALANCE:
RECOMMENDED LOAD RESISTANCE:
COMPLIANCE:

CHANNEL SEPARATION:

STYLUS:

CARTRIDGE WEIGHT:

SUBFUNCTIONS:
ACCESSORY:

POWER REQUIREMENT:
POWER CONSUMPTION:
DIMENSIONS:

WEIGHT:

Two speeds stereo record player system

Belt drive system

33-1/3 Lam. and 45 r.p.m.

Four poles synchronous motor

Selector lever system

12" [30 cm) diameter, aluminum-discus! alloy.
007% (WRMS) or less.

45 dB or more,

Static balanced. S-shape type pipe arm with direct read out stylus
pressure and anti-skating control system.

8,464" (215 mm]

4 to 10 915.

Dual magnet type (JM-18l.

15 Hz. - 20 kHz.

2 art.

2.5 mV (M1 kHz, 50 mlm sec.)
Within 2 dB (at 1 kHz.)

47 Kohms. ,

6x 10 cm/dyne.

20 db or more (at I kHz.)

0.6 mil, diamond (type DSNGQI
5.5 grs.

OiI damping pick-up arm lifter.

Large size shock insulators.

Autovcut, auto-return tone arm mechanism.
45 rpm. adaptor.
AC 220 volts 50 Hz.
15 Watts.

135.116" (465 mlmlw x 14-29/64 (367 mfmID x 645/3 (168
m/MJH.

15.4 lbs. (7.0 kgrs)

' Far North America 117V 60 Hz.
