Scott LT 10 Assembly Manual

Page 2

Hermon Scott TN Important

Hermon II. Scott received 8.8 .aml M S. dean-en from

o
M.l.'l . Inventor of the R( Oscillator. RC tuned circuits I";
H. Flrsts...

and filters, the Dynamic Nome bnppressor and other
devices, he has many U. S. and foreign pawnts. His

technical leadership was recognized by election as llol- HY H- H SCOTT

low in the Institute of Radio Engineers. Acoustical . . .

Socicty of America. and Audio Engineering Society. FlrSt hlgh fidEhty AM'FM Stereo
and by numerous awards, including the Potts Medal. tuner using wide range AM design.
He is the author of many technical papers and articles. First to successfully use wide-band

circuitry in high-fidelity FM tuners.
First to market The Stereo-Daptor, a
stereo control unit that prevents ob-
solescence. First to provide center
channel ouput on Stereo amplifiers
for added realism in playback.

Page 20

Assembly Group B- 7

Era/Lg m/mmg/gfim:

18

B- 1-2.
3-7-3.
3-7-4.
3-1-5.
3-1-6.
3-1-7.

3-7-8.

3-1-9.
57-10.

B-I-ll.

Connect 11 CC .02 from pin 1,81 to ground lug A on SI (SI)

Connect a 4 wire from pin 1,81 to pin 5, SE.

Connect a CC-.0047 from pin 4, VI to L7 (S2).

Connect a CC-.0047 from pin 3, T2 to L4.

Conneota CC-.0047 from pin 3, V2 to L6 (S3).

Connect 3 00.0047 from pin 7, V2 to L3.

Connect a CC-.0047 from pin 3, T3 to L3.

Connect a 470k resistor (yellow, purple, yellow) from pin 1. 31 (8.3) to pin 1, V1.
Connect a 68 ohm resistor (blue, grey, black) from pin 7, V1 (51) to L4 (SB).
Connect :1 33K resistor (orange, orange, orange) from pin 4, SE to pin 5, 85 (S3).
Connect one end of a 2.2 M resistor (red, red, green) to pin 4, J2 (82). Push the

other end through the hole in Pin 3, J2 and connect to pin 2, J2. Solder the hole in
pin 3, J2. (52).

(Check all wires, connections. and soldered joints before continuing. Make sure your layout
looks exactly like the diagram above.)

Page 22

Q-

3-9-5.
3-9-6.

3-9-7.

E 3-9-8.

Connect a choke (10 mh) from pin 4, V1 to pin 3, V2 (S3).

Connect a CC.1 (brown, black. grey) from pin 2. T2 (82) to pin 4, T2 (82). Position this
capacitor so that it does not block the hole in the bottom of the transformer can (the

alignment hole).

Connect a 220 ohm resistor (red, red, brown) from pin 7, V2 (82) to L3.

Connect a CC .001 from pin 4, S5 to L3 (S4).

Connect a CC ,001 from pin 2, 56 to ground lug A, SS (SI).

Connect a 47 K resistor (yellow, purple, orange) from pin 2, SE to pin 4, S5 (S3).

Slide 3 1 piece of black insulation material (spaghetti) over the end of a CPM .l with the
black band, and connect this end to pin 1, V3, (S3). Connect the other end to pin 1, S2.

Connect a CC '22 (red, red, grey) from pin 2, T3 (82) to pin 4, T3 (82). Position this
capacitor so it does not block the large hole in the bottom of the transformer can (alignment

hole).

(Check all wires. connections, and soldered joints before continuing. Make sure your layout
looks exactly like the diagram above.)
