Sanyo mcd zx600f
This is the 15 pages manual for sanyo mcd zx600f.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sanyo mcd zx600f (Ocr-read)
Page 1
- 1 - CAUTION : USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. LASER OUTPUT ................ 0.6 mW Max. (CW) WAVE LENGTH ................. 790 nm - Pickup that emits a laser beam is used on this CD section. LASER BEAM SAFETY PRECAUTION CAUTION-INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM. ADVARSEL-USYNLIG LASER STRÅLING VED ÅBNING, NÅR SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION, UNDGÅ UDS ÆTTELSE FOR STRÅLING. VARNING-OSYNLIG LASER STRÅLNING NÄR DENNA DEL ÄR ÖPPNAD OCH SPÄRR ÄR URKOPPLAD. STRÅLEN ÄR FARLIG. VORSICHT! -UNSICHTBARE LASERSTRAHLUNG TRITT AUS, WENN DECKEL GEÖFFNET UND ENN SICHERHEITSVERRIEGELUNG ÜBERBRÜCKT IST. NICHT, DEM STRAHL AUSSETZEN. VARO !-Avattaessa ja suojalukitus ohitettaessa olet alttiina näkymättömälle lasersäteilylle. Älä katso säteeseen. CLASS 1 LASER PRODUCT LUOKAN 1 LASERLAITE KLASS 1 LASERAPPARAT IC BLOCK DIAGRAM & DESCRIPTION IC301 TA8227 (Power Amp.) IC501 LC75342(Function SW) CONTROL CIRCUITLOGIC CIRCUITCCB INTERFACE CONTROL CIRCUIT 15 14 16 17 18 19 20 21 22 24 25 2623 10 9 7 6 58 11 L4 L3 L2 L1 NC NC R1 R2 R3 R4 RSELO RIN RTRE RBASS1 RBASS2 ROUTLSELO LIN LTRE LBASS1 LBASS2 LOUT TEST V SS CE DI CL V DD Vref NC 12 13 1 2 30 29 28 274 3 LVref RVref 1 2 3 Pin No. Function 1 INPUT 2COMMON 3 OUTPUT IC401 KIA7808(Voltage Regulator)
