- 1 - SAFETY PRECAUTION TUNER ADJUSTMENTS BAND FM-IFSTEP 1SING. FRE. 10.7MHzADJUST- MENT T801 T803REMARKS ADJUST FOR BEST IF WAVE FORM & S CURVE RADIO SETTING BAND AM-IFSTEP 1SING. FRE. 455KHz (CA,PA) 460KHz (Except CA,PA)ADJUST- MENT T802REMARKS ADJUST FOR BEST IF WAVE FORM RADIO SETTING (1). AM IF ADJUSTMENT (2). FM IF ADJUSTMENT AM LOOP ANT (FIG.2) (FIG.1) 300PF R807 IC801 7 PINIC801 7 PIN 0.1U0.1U 10.5 10.7 10.9 WAVE FORM (MHZ)455 KHz or 460KHz WAVE FORM CAUTION : USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE LASER OUTPUT .......... 0.6 mW Max. (CW) WAVELENGTH ............. 790 nm PART LOCATION CAUTION – INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM. ADVARSEL – USYNLIG LASER STRÅLING VED ÅBNING, NÅR SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION, UNDGÅ UDS ÆTTELSE FOR STRÅLING. VARNING – OSYNLIG LASER STRÅLNING NÄR DENNA DEL ÄR ÖPPNAD OCH SPÄRR ÄR URKOPPLAD. STRÅLEN ÄR FARLIG. VORSICHT – UNSICHTBARE LASERSTRAHLUNG TRITT AUS, WENN DECKEL GEÖFFNET UND WENN SICHERHEITSVERRIEGELUNG ÜBERBRÜCKT IST. NICHT, DEM STRAHL AUSSETZEN. VARO – AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALTTIINA NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN.

Page 2

- 2 - TUNER ADJUSTMENTS ADJUSTMENT ANT COIL TC4 (PVC TRIMMER) ADJUST FOR MAXIMUM SENSITIVITY MAXIMUM SENSITIVITY SING. FRE. 600KHz 1400KHz BAND AMSTEP 1 2 3 REPEAT STEP 1 AND 2 SEVERAL TIMES ADJUSTMENT L802 TC2 (PVC TRIMMER) ADJUST FOR MAXIMUM SENSITIVITY MAXIMUM SENSITIVITY SING. FRE. 90MHz 106MHz BAND FMSTEP 1 2 3 REPEAT STEP 1 AND 2 SEVERAL TIMES (4). AM TRACKING ADJUSTMENT Signal Generator ...... Connects to the AM ANT. Coil througt the loop antenna. Adjust for the indication of VTVM of the wave form scope to be maximum. (5). FM RF TRACKING ADJUSTMENT Signal Generator ...... Connects to the FM ANT JACK (FM IN) through the dummy. AC EVM FM-SGAM-SG OUT 75 OHM FM ANTOUTPUTOSCILLOSCOPEOSCILLOSCOPE AM BAR ANT 60cm (FIG.4) (FIG.5)AC EVM ADJUSTMENT L803 TC1 (PVC TRIMMER) ADJUST FOR MAXIMUM SENSITIVITY MAXIMUM SENSITIVITY SING. FRE. 87MHz (CA,PA) 87.35MHz (Except CA,PA) 109MHz (CA,PA) 108.5MHz (Except CA,PA) NO. 1 2 3BAND FM FM REPEAT STEP 1 AND 2 SEVERAL TIMES ADJUSTMENT L804 TC3 (PVC TRIMMER) ADJUST FOR MAXIMUM SENSITIVITY MAXIMUM SENSITIVITY SING. FRE. 515KHz 1740KHz (CA) 1640KHz (Except CA) NO. 4 5 6BAND AM AM REPEAT STEP 4 AND 5 SEVERAL TIMES FM Band: Set the internal modulation of Singnal generator to 1 KHz Dev. 22.5KHz AM Band: Set the internal modulation of Singnal generator to 30Ë1KHz FM BAND AM BAND (3). TUNING FREQUENCY RANGE ADJUSTMENT AC EVM FM-SG AM-SG75 OHM FM ANTOUTPUT OUTPUTOSCILLOSCOPE OSCILLOSCOPE AM BAR ANT. 60cm (FIG.3)
