Page 2

SAIMYO

FILE NO.

Separate Mini Component DC-007C (UK)
System (x5)

Service Manual

PRODUCT CODE No.
129 569 00 (UK)
129 569 01 (XE)

Specifications

TUNER SECTION
Reception frequency ........ FM : 87.5 - 108 MHz

AM 5 522 - 1161 kHz Output ........... OPTICAL DIGITAL our : Optical
Output power ................... 50W x2 (1kHz at 6 ohm, power supply . Supplied from the Tuner/Ampmier
10% dismmon) Dimensions . 270 (W) x 87 (H) x 276 (D) mm
Inputs .. VIDEO (AUDIO) : 500 mV/50k ohms Weight .......... 2_3 kg
Outputs.. .. SPEAKERS : 6 ohms
PHONES I 8 - 32 ohms wmess REMOTE CONTROL
_ SUB WOOFER OUT 1 10" ohms Power requirements ......... 2 "R6 (HP7)" batteries
Power requrrements - Dimensions . Approx. 66(W) x 200(H) x 32(D)mm
Power 0°msumpll°n Weight ........ . Approx. 1159 (without batteries)
0.8W (Ecology On standby mode)
16W (Ecology Off standby mode) SPEAKER SYSTEM
Dimensions -- -- 270 (W) X 122 (H) X 287 (0) mm Type ................................ 3 way bass reflex
Weight .. 5.3 kg Built-in magnetic stray field
compensation
CD PLAYER SECTION . Unit used ......................... Woofer : 15 cm cone type
Type .......... ..Changer, 3-disc Mid range : 8 cm cone type
Channels" -- 2-channel 516' Tweeter: 3.5 cm balance driver
Sampling frequency .. 44.1 kHz Maximum power-handling
Pick-up ......... .. Optical 3-beam semiconductor laser capacity ________________ 100W (peak)
Laser output . .. 0.6 mW (Continuous wave max.) Nominal impedance ' 6 ohms
Wave length - -- 790 m Dimensions 230 (W) x 343 (H) x 253 (D) mm
Frequency response -- 20 Hz to 20 kHz Weight ........ 4.7 kg (per speaker)
Wow/flutter 4. Below measurable limits
OUIpUI .......... .. OPTICAL DIGITAL OUT : Optical Specifications subject to change without notice.

'-This service manual consists of "JCX- 007" (T uner/Amplifier UK: 129 561 00, XE: 129 561 01),-I
"DAD-CP-007" (CD Changer UK. 137 087 00, XE. 137 087 01), "RB- 007" (Rmote control), I
SX- 007L" (Speaker system. 165 000 00) and "SX- 007R" (Speaker system: 165 001 00).

REFERENCE No. SM5810033

SYSTEM CONNECTIONS

CD changer

fiWhen using only the system DC-007C (CD changer and Tuner/Amplifier)

Tuner/Amplifier

The flat connection lead is
provided as shown. ,

To the CD
changer z

Fixer Tape

To the Tunerl ..
Amplifier <:==~4.

Do not remove the fixer and
protective tape.

Notes on the flat connection lead
When using the system DC-OOYC (CD
changer and Tuner/Amplifier) and
optional Tape deck and/or MD deck,
remove the fixer and protective tape
before connecting.

- Do not remove the tape on the plug

that is not used.

Note:

- Do not connect the mains lead to
an Ac outlet until all connections
have been made.

- The system is not completely dis-
connected from the mains when
the (DION button is set to the d)
position.

- To prevent a noise interference from
the mains, the core clamp is at-
tached to the mains lead. Do not
remove it.

Before connecting,
remove the cap on this

socket. E

Digital equipment

-- (Optical cable,
Video equipment/DVD not supplied)

player

MD deck

To connect, push the middle of
the plug and insert it until it clicks.

To disconnect, while pressing
both latches, remove the plug.

If you have difficulty inserting the
L plug, turn it over and reinsert it. '

CD changer

(Flat connection lead)

(Optical cable, supplied
with the MD deck)

_ (Audio leads, not
supplied)

Tape deck
Amplified subwoofer

l l Tuner/Amplifier

(Audio lead, not

supplied)

To an AC outlet
