Sansui R 5 Service Manual
This is the 18 pages manual for Sansui R 5 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Sansui R 5 Service Manual (Ocr-read)
Page 17
6. REPLACEMENT OF DIAL CORD
o lf a dial cord is cut off or slips, replace it by following pro-
cedures. As this unit uses 0.5 mm¢ card, please replace it with
the same type certainly.
6-1. Threading of Dial Cord
Thread the dial cord in numerical order from® to ® as Fig, 6-1.
a Close the variable capacitor completely.
* Dial Card (0.5 mma) ........ (Stock No. 60360500)
* Dial Pulley. 0-44 Type ....... (Stock No. 07776900)
@ mafia»
Pulley
6-2. Attachment of Dial Painter
1. Close the variable capacitor campletely.
2. Set the dial pointer to the start point, the line at the left and of
the dial scale. (Fig. 6-2)
Confirm that the dial pointer runs smoothly on the dial scale by
turning the turning shaft.
11
Fig. 6-2 Clip
Rod,D|al Pointer Holder
Dial Pointer Holder Indicator
\
Threading of
/Dial Cord
Start Point
