We are grateful for your choice of the Sansui QRX-7001 4-channel receiver.
Before you begin to operate it, may we suggest that you read this booklet of
operating instructions once carefully? You will then be able to connect and
operate it correctly, and enjoy its superb performance for years.

OFUNCTIONAL FEATURES

Olncorporates a QSt Synthesizer circuit to reorganize
conventional 2-channel stereo signals and create a 4-
channel sound field.

OThe built-in QS regular matrix system 4channel de-
coder decodes 4-channel records and tapes encoded
with the regular matrix system such as the Q5 system,
and their broadcasts, to reproduce them as a pérfect
4-channel sound field.

OThe built-in Phase Matrix circuit, featuring Sansuis
own front-back logic, decodes records and tapes en-
coded with the SQ system to properly reproduce them
in 4-channel stereo.

OThe new Sansui-improved built-in CD-4** demodu-
lator makes it possible to reproduce CD-4 4-channel
records, with increased inter-channel separation.
OIncorporates PHONO inputs, two 4-channel tape
record/playback circuits. The 4-channel front inputs can
be in exactly the same manner as 2-channel inputs, for
either ordinary 2-Channel reproduction or 4-channel
reproduction through the built-in 4-channel decoding
circuit.

OFacilities for independent adjustment of tonal quality
in the front and back channels.

OFor the reception of FM broadcasts, provisions are
made for both 75-ohm and 300-ohm FM antenna termi-
nals. Connection is extremely simple when setting up
an outdoor antenna using either a 75-ohm unbalanced
coaxial type lead-in cable or a 300ohm balanced feeder
type lead-in cable.

<>Unpleasant noises heard in the lows and/or highs can
be eliminated by activating the pushbutton FILTER
switches on the front panel.
