Sansui P M55 Service Manual

Page 1

SERVICE WNU AL OSPECIFICATIONS

Type ................................ Direct-drive turntable
Rated speeds.. ..... 33-1/3, 45 rpm
Platter ............................. Aluminum alloy diecast,
COMPUTER CONTROL 306 mm (12-1/16) diameter,
LINEAR TRACKING/FULLY AUTOMATIC DD TURNTABLE 0-6 k8 -3 'st we'ght
Motor ............................. Coreless and Brushless

DC/FG Servo

Wow/flutter .................... 0.028% (WRMS)
- Signal-to-noise ratio ........ Better than 72 dB (DIN-B)
Better than 60 dB (IECB)

Tonearm ......................... Statically-balanced type
Effective tonearm length
.................................. 142 mm (5-5/8)

Cartridge ......................... Dual Magnet type (SV-PS15)
Output voltage ................ 2.5 mV (1,000 Hz, 35.4
mm/sec)

Correct load impedance
.. 47 kohms
.. lO~20,000 HZ

Frequency response.

Stylus .............................. 0.6 mil diamond stylus
(SN-P515 replacement stylus)

Others

Power voltage ................. 1 10~120l220~ 240V (50/60

Hz)
For U.S.A. and Canada
............................... 120 V (60 HZ)

Power consumption .. 15 W

Dimensions ..................... 345 mm (13-5/8) W
99 mm (3-15/16) H
360 mm (14v3/l6") D

Weight ............................ 5.5 kg (12.8 lbs.) net
6.4 kg (14.6 lbs.) packed

Design and specifications subject to change without
notice for improvements.

CAUTION

1. Use only replacement parts recommended by
the manufacturer.

2. Measure insulation resistance before returning
the appliance to the customer to prevent elec-
trical shock.

Sansui.
SANSUI ELECTRIC CO., LTD.
