Sansui P E750 Service Manual

Page 1

arts Idertifa

Page 2

P-E750

- 0 Abbreviations List

CAUNON

1. The symbols, UL, CSA, SA, BS, UK, EU, AS and XX on the parts

list and the schematic diagram mean followings respectively.

UL ................. Manufactured for USA market. .
(Underwriters Laboratories approved model.)

CSA ............... Manufactured for Canadian market.

SA ................. Manufactured for South African market.

BS, UK ........... Manufactured for United Kingdom market.

EU ................. Manufactured for European market.

AS ................. Manufactured for Australian market.

XX ................ Standard Version.

NON MARK ..... Common Parts.

2. Some printed circuit boards are not supplied as the assembled.

To separate these in this service manual, the stock Nos are not
indicated at the ends of the board names. However, the individual
parts on the circuit boards are provided by orders.

_ 3. Since some of capacitors and resistors are omitted from parts lists

in this service manual, refer to the Common Parts List for capaci-
tors & resistors, which was issued on February 1983.

4. Abbreviations in this service manual are as follows.

C.R. : Carbon Resistor E.B.L. : Low Leak Bi-Polar
S.R. : Solid Resistor Electrolytic Capacitor
Ce.R : Cement Resistor Ta.C. : Tantalum Capacitor
M.R. : Metal Film Resistor F.C. : Film Capacitor
F.R. : Fusing Resistor M.P. : Metalized Paper
N.LR. :Noanflanunabb Resbtor Capachor
A.R. : Array Resistor F.C. : Polystyrene Capacitor
C.C. : Ceramic Capacitor G.C. : Gimmic Capacitor
C.T. : Ceramic Capacitor, A.C : Array Capacitor
Temperature Compensation V.R. : Variable Resistor
E.C. : Electrolytic Capacitor S.V.R. : Semi Variable Resistor
E.L. : Low Leak Electrolytic SW. : Switch
Capacitor Chip R. : Chip Resistor
E.B. : Bi-Polar Electrolytic Chip C. : Chip Capacitor

Capacitor
