Sansui CD 2100 Service Manual

Page 1

1 ISERVICE MANUAL

SANSUI

CD-2IDD

nun D/A mvtartn

COMPACT DISC PLAYER

L-I

CAUTION

1. Parts identified by the A symbol on the schematic diagram and the parts list are critical for safety.
Use only replacement parts that have critical characteristics recommended by the manufacturer.

2. Make leakage-current or resistance measurements to determine that exposed parts are acceptably
insulated from the supply circuit before returning the appliance to the customer.

1. The symbols UL, SS and XX on the pans list and
the schematic diagram mean followings respectively.

UL ......... Manufactured for U.$.A. market.
(Underwriters Laboratories approved model.)

55 ......... Manufactured for Saudi Arabian market.

XX ......... Standard Version.

< EXPORT)

NON MARK . . . Common Parts,

2, Some printed circuit boards are not supplied assembled. To
separate these in this service manual, the part numbers are not
indicated for these boards. However, part numbers for individual
parts are indicated.

3. Since some capacitors and resistors are omitted from parts lists in
this service manual, refer to the Common Parts List for capacitors
and resistors, which was issued on June 1987.

NOTICE

4 Abbreviations in this service manual are as follows:

: Carbon Resistor

: Solid Resistor

: Cement Resistor

: Metal Film Resistor

: Fusing Resistor

R.: Nonvlnflammable
Resistor

: Array Resistor

: Ceramic Capacitor

: Ceramic Capacitor,
Temperature
Compensation

E.C, : EIectrolvticCapacitor

E.L, : Low Leak Electrolytic

Capacitor
E.B. : Bi-Polar Electrolytic
Capacitor

' N
a.

on? zrzgwo
{was

7'0?

Abbreviations List

E.B,L.: Low Leak Bi-Polar
Electrolytic
Capacitor

Tantalum Capacitor

Film Capacitor

: Metalized Paper
Capacitor

: Polystyrene Capacitor

.: Metalized Mylar
Capacitor

: Array Capacitor

Variable Resistor

Semi-Variable Resistor

Switch

Chip Resistor

Chip Capacitor

: Styrol Capacitor

-l
m
(1

S} .33 37
$700 3. 370'
h ,

x

Llilli
.:

Specifications

Format ................ Compact disc, digital audio
system
Pickup ............... 3-beam, semiconductor laser

, 5 Hz to 20 kHz, 20.5 dB
Less than 0.05% (1 kHz)
Better than 100 dB
Better than 95 dB

Frequency response .

Total harmonic distorti
Signal-toNoise ratio
Dynamic range . .

on

Rated power consumption .....
Dimensions ..............

Weight .................

13W

430 mm (16-15/16) W
93.5 mm (3-11/16) H
286 mm (il-S/ié") D
4.3 kgs (9.5 lbs) net

Wow & flutter . . .
Output voltages/load Impedances

Powerconsumption
For U,S.A. & Canada

Below measurable limit

2V/47 kohms or more
AC 120, 220-7240V (50/60 Hz)
AC l20V, 60 Hz

Design and specifications subject to changes without notice for
improvements

Due to local laws and regulations, this unit said in some areas are
not equipped with variable voltage selectors.

Page 2

CD-2100

1. SAFETY PRECAUTIONS FOR CD PLAYER

CAUTION: USE OF CONTROLS FOR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECI FIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
THE COMPACT DISC PLAYER SHOULD NOT BE ADJUSTED 0R REPAIRED BY ANYONE EXCEPT PROPERLY QUALI-

FIED SERVICE PERSONNEL.

" The following label has been affixed to the unit, listing the proper
procedure for working with the laser beam,

(UL and XX model only)

PRODUCT COMPLIES WITH DHHS
RULES 21 CFR, SUBCHAPTER J.
PART 1040. JO.

MANUFACTURED:

For the Customers

This equipment generates and uses radio frequency energy and if
not installed and used properly, that is, in strict accordance with
the manufacturers instructions, may cause interference to radio
and televisron reception.

lt has been type tested and found to comply With the limits for a
Class B computing device in accordance with the speCifications in
Subpart J of Part 15 of FCC Rules. which are designed to provide
reasonable protection against such interference in a residential
installation. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:

relocate the equipment with respect to the receiver

move the equipment away from the receiver

plug the equrpment into a different outlet so that equipment
and receiver are on different branch circuits.

If necessary, the user should consult the dealer or an experienced
radio/television technicran for additional suggestions. The user
may find the followmg booklet prepared by the Federal
Communications CommiSSion helpful: How to ldentify and
Resolve Radio ~TV Interference Problems. This booklet rs
availaole from the US Government Printing Office, Washington,
DC , 20402, Stock No.004-000700345-4.
