Sansui BAF 1 Owners Manual

Page 1

Bil-Fl

OPERATING INSTRUCTIONS

.31! this manuélbfilflfiuu.

www.hifiengine.com

Page 2

We are grateful for your choice of this fine Sansul high fidelity product.
Before you operate it. we suggest that you real this booklet once
through carefully. familiarizing yourself with the important or
tions, operational procedures and every one of the products r i
features. It will help to ensure that youwill avoid possible damage and
that the product's superb performance will be yours to enjoy for many
years to come.

Table of contents

Precautions 4
Connections 3
Panel information . . .11
Operating procedures .16
Some useful hints . . . .18
Specifications . . 22

WARNING: To prevent fire or shock hazard.

do nor expose this appliance to rain or
moisture.

o The Model No. and Sari-l No. of your unit are shown on its back
pad.

o 00 not low the Warranty Card that carrier your unit's Model No.
and Sari-l No.

www.hifiengine.com

Page 9

Left Output

0 I

Left lml

MI

Operating procedures

1. First turn volume control of connected preamplifier to lowest Mai.
Then switch preamplifier power on.

3 Switch the unit's power on. The PROTECTOR indicator Wiillli
up and then go off 6114* a few seconds. .

3. Set the OUTPUT selectors to A. B or A + B position as appropnata.

4. Turn LEFT and RICHT LEVEL controls together to maximum
level (10!.

5. Operate and play equipment connected with the preamplifier. 5km-
Iy adjust preamplifier volume controluntil desired volume is re
ached.

6..ediust balance and tone controls on preamplifier. as needed. and
enjoy your music.

0 For best performance and balance. it is recommended that you set
the unit's LEVEL controls at the maximum setting CH. and adjust
your system's volume with the volume control on the preamplifier.
