Sansui Straight DC Stereo Control

Preamplifier

The spec sheet reads like an engineers dream. Frequency
response is 5 to 600kHz! THD and 8/ N are better than 0.005% and 90dB
respectively. But while these steady-state specs are remarkable-in them-
selves, the transient response of the Sansui CA-Ft is even more impressive.

As in our newest DC power amps, weve concentrated on
improving slew rate, lowering TIM and envelope distortion, and providing
the closest thing possible to real-time rise/fall characteristics so that
pulsive musical signals are reproduced with more natural sound quality.
Achieving all this without sacrificing the steady-state specs is a significant
triumph in audio engineering for Sansui, and is the result of our Straight
DC design in which major circuit blocks are DC.

The CA-F1 features the Sansui-exclusive Diamond Differ-
ential DC circuit ( DD/ DC) for its phono equalizer. As youd expect in a pre-
amplifier of this quality, in spite of its moderate price, there is also a built-in
MC head amplifier (or Dre-preamp) for Moving Coil cartridges. And theres
a lot more. Visit your Sansui dealer soon. ,
